Fixing tie with pipe/tube holder, Ø108.0mm, black, 200pcs.
Art.-No. 156-03382 | T120RIAHC3TCR-PA66HIRHS-BK | Details

2-piece fixing tie, 360° rotatable, a cable tie in combination with an AHC to route and fix harnesses.

Add to watchlist

Request your individual offer now

Request quote

More products in this product group:

2-piece fixing ties with automatic harness clip >

Base Data

Application	Offering a simple and secure method of attaching cables together. Originally designed for the automotive industry, these products are used in a wide range of applications.
Application Tool	ProCut 9 no battery, EVOcut, MK9P, MK9P w/ Upper air, MK10-SB, MK21, EVO9SP, EVO9HT, EVO9i, EVO9iSP, EVO9iHT
Colour	Black (BK)
Identification Plate Position	none
Key product features	rotatable, for multiple routing, lockable, removable
Material	Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
PART DESCRIPTION	T120RIAHC3TCR-PA66HIRHS-BK
Pack Content	200pcs.
Package Content packed in	bag
Product Family	IAHC-Series
Product Group	2-piece fixing ties with automatic harness clip
Type	T120RIAHC3TCR

Product Dimensions

Attach to Ø	19.0 - 28.0
Bundle Diameter max (metric)	108.0mm
Length (L)	390mm
Min.Tensile Strength	530N
Thickness (T)	1.8mm
Width (W)	7.6mm

Downloads

Specifications

ELV compliant (Article 4 - 2)	YES
Hazardous Goods	No
ROHS compliant	Yes
Specifications

Logistics and Packaging


GTIN-13 / EAN	4031026659596
Packaging 3 - Qty	200
Packaging 4 - Qty	4800

More Information

UNSPSC Key

39121717
