Fixing tie for edge, inside serrated, Ø1.0-20.0mm, black, 500Set
Art.-No. 156-00962 | T18REC10SDSET-PA66HS/PA66HIRHS-BK |  Details

T50ROSEC10 fitted onto a plastic panel to hold a Ø 6 mm harness.

    Package size
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application Tool MK3PNSP2, EVOcut, MK7P, MK10-SB, MK20, EVO7, EVO7SP, EVO7i, EVO7iSP
    Colour Black (BK)
    Content 500 T18R + 500 EC10SD
    Identification Plate Position none
    Key product features for narrow bundling
    Material Polyamide 6.6, heat stabilised (PA66HS), Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    PART DESCRIPTION T18REC10SDSET-PA66HS/PA66HIRHS-BK
    Pack Content 500Set
    Package Content packed in bag
    Releasable Closure (Yes/No) No
    Tie Closure plastic pawl
    Type T18REC10SDSET
    Variant Inside Serrated
    Bundle Diameter max (metric) 20.0mm
    Bundle ∅ min. 1.0mm
    Height (H) 1.0mm
    Height (H2) 12.0mm
    Length (L) 100.0mm
    Length (L2) 15.0mm
    Min.Tensile Strength 80N
    Width (W) 2.45mm
    Width (W2) 11.0mm
    for Panel Thickness min - max 1 - 3 mm
    ROHS compliant Yes
    Specifications
    GTIN-13 / EAN 4031026450254
    UNSPSC Key 39121731
