Cable tie mount for adhesive use, black, 100Bag
Art.-No. 151-03196 | PMB8-PA66/6HIRHS-BK 세부

  • PMB paste adhesive mount for fixings with paste / liquid adhesive
  • Mount geometry offers a good form closure with cured adhesive
  • Can even be installed onto uneven surfaces
Application PMB-Series offers a fixing solution wherever screw fixing is not allowed. Due to the design the mounts can even be installed onto uneven surfaces. PMB paste mounts are used in the railway industry as well as in the renewable energy industry. Further applications are in the electrical industry and the production of switching cabinets. PMB-Series is suitable for fixings with paste/liquid adhesive.
Articolo PMB8
Caratteristiche principali del prodotto adesivo liquido/pasto, superfici irregolari
Colore Nero (BK)
Cont. conf. 100Sacchetto
Descrizione Breve Basetta per pasta adesiva 50x47 mm, PA66HIRHS, nero
GLOBAL PART DESCRIPTION PMB8-PA66/6HIRHS-BK
Materiale Poliammide 6.6/6 ad elevata resistenza meccanica e stabilizzata al calore (PA66/6HIRHS)
Metodo di fissaggio Incollato / Adeso
Prodotto: Categoria Basetta per pasta adesiva
Prodotto: Famiglia Basetta PMB per superfici irregolari
Quantità per confezione
Altezza (H) 11.2mm
Largh. (W) 47mm
Largh. max fascetta (G) 13mm
Lungh. (L) 50mm
Peso Netto 0.007175kg
org.mozilla.javascript.Undefined@0 SI
Certificazioni
Temp. di esercizio - °C da -40 °C a +85 °C
org.mozilla.javascript.Undefined@0 No
Conformità RoHS
Codice EAN 4031026643779
Codice doganale 39269097
PL1_Dim. Altezza 0.15m
PL1_Dim. Larghezza 0.26m
PL1_Dim. Lunghezza 0.3m
PL1_Peso 0.731362kg
PL1_Quantità 100
PL1_Tipologia confezione
PL1_Volume 0.0117
PL3_Dim. Altezza 0.204m
PL3_Dim. Larghezza 0.398m
PL3_Dim. Lunghezza 0.591m
PL3_Peso 9.426344kg
PL3_Quantità 1200
PL3_Tipologia scatola
PL3_Volume 0.048
PL4_Dim. Altezza 1.164m
PL4_Dim. Larghezza 0.8m
PL4_Dim. Lunghezza 1.2m
PL4_Peso 209.56kg
PL4_Quantità 24000
PL4_Tipologia pallet
PL4_Volume 1.117
Paese d'origine DE
org.mozilla.javascript.Undefined@0 EC000449
ETIM 8.0 Key EC000449
org.mozilla.javascript.Undefined@0 39121717
ETIM 9.0 Key EC000449
