Fixing tie for hole (round), outside serrated, Ø1.0-32.0mm, beige, 100pcs.
Art.-No. 156-01146 | PT2AP3SFT6.5-PEEK-BGE 세부

  • Pre-assembled 2-piece fixing tie with arrowhead foot part
  • Cable tie head can be moved after bundling
  • Easy to assemble without the need for a tool
  • Arrowhead simply locks into place
  • Disc adjusts tie for pressure from various directions and minimises access of dust, dirt and water
  • Features Material PEEK
  • -55 °C to +240 °C operating temperature
  • Excellent resistance against chemicals and gamma radiation
Show more
Application The ties with fixing element P1SFT6,5 or P2SFT6,5 are ideal when the requirement for temperature or chemical resistance is very high. They are used for cable harnesses in the automotive industry.
Articolo PT2AP3SFT6.5
Colore Beige (BGE)
Cont. conf. 100Pz.
Descrizione Breve Fascetta fissaggio a freccia PT2AP3SFT6.5
GLOBAL PART DESCRIPTION PT2AP3SFT6.5-PEEK-BGE
Materiale Polietheretherketone (PEEK)
Metodo di fissaggio Punta di freccia
Prodotto: Categoria Fascette di fissaggio 2-piece con ancoraggio a freccia e disco
Prodotto: Famiglia Per temperature fino a +240°C
Quantità per confezione
Tipo di serraggio dente in plastica
Utensile MK3PNSP2, EVOcut, MK7P, MK10-SB, MK20, EVO7SP, EVO7i, EVO7iSP
Variante A dentatura esterna
Carico rottura min 230N
Diametro legatura (mm) 1.0-32.0mm
Largh. (W) 3.4mm
Lungh. (L) 145.0mm
Peso Netto 0.001232kg
Spessore (T) 1.2mm
Spessore pannello 1.2 –1.8mm
Spessore pannello (metrico) 1.2 - 1.8 mm
∅ disco 16.0mm
∅ foro fiss. (FH) 6.3 - 6.7 mm
∅ legat. max 32.0mm
∅ legat. min 1.0mm
Certificazioni
Conformità RoHS
Infiammabilità UL 94 V0 (3mm)
Temp. di esercizio - °C da -55 °C a +240 °C
Codice EAN 4031026469720
Codice doganale 39269097
PL1_Dim. Altezza 0.045m
PL1_Dim. Larghezza 0.32m
PL1_Dim. Lunghezza 0.275m
PL1_Peso 0.137062kg
PL1_Quantità 100
PL1_Tipologia confezione
PL1_Volume 0.00396
PL3_Dim. Altezza 0.204m
PL3_Dim. Larghezza 0.398m
PL3_Dim. Lunghezza 0.591m
PL3_Peso 3.72724kg
PL3_Quantità 2000
PL3_Tipologia scatola
PL3_Volume 0.048
PL4_Dim. Altezza 1.235m
PL4_Dim. Larghezza 0.8m
PL4_Dim. Lunghezza 1.2m
PL4_Peso 95.6kg
PL4_Quantità 40000
PL4_Tipologia pallet
PL4_Volume 1.186
Paese d'origine DE
ETIM 8.0 Key EC000046
ETIM 9.0 Key EC000046
