Cable clip for adhesive use/with pipe/tube holder, Dmax=5.0mm, natural, 100pcs.
Art.-No. 151-14059 | RB5-PA66-NA 세부

  • Flat design to use in applications with limited space
  • One-piece self adhesive mount for quick and easy installation
  • Can be used without cable ties offering process optimization
  • Different sizes for various bundle diameters available
  • Cost effective with easy application on smooth, clean surfaces
Show more
Application RB-Series self adhesive mounts offer greater routing freedom and also reduce the risk of corrosion compared to screw fixing mounts. They are ideally suited for tool-free installation and can be re-opened and reused easily when cables need to be replaced. These mounts can be used without the need for additional cable ties. Offering process optimization in a variety of applications.
Articolo RB5
Colore Naturale (NAT)
Cont. conf. 100Pz.
Descrizione Breve Clip adesiva RB5
GLOBAL PART DESCRIPTION RB5-PA66-NA
Materiale Poliammide 6.6 (PA66)
Metodo di fissaggio Incollato / Adeso
Prodotto: Categoria Clip con adesivo
Prodotto: Famiglia Serie RB con disegno piatto
Quantità per pz
Variante Chiuso
Altezza (H) 6.0mm
Diametro legatura (mm) 5.0mm
Largh. (W) 19.0mm
Largh. (W2) 9.7mm
Lungh. (L) 19.0mm
Peso Netto 0.001047kg
∅ legat. max 5.0mm
∅ nominale 5.0mm
∅ nominale (imperiale) 0.19"
Zero Alogeni
org.mozilla.javascript.Undefined@0 SI
Adesivo Gomma sintetica con base di schiuma di Polietilene
Certificazioni
Temp. di esercizio - °C da -40 °C a +60 °C
org.mozilla.javascript.Undefined@0 No
org.mozilla.javascript.Undefined@0 No
Conformità RoHS
Infiammabilità UL 94 V2 (escluso adesivo)
Temperatura di esercizio adesivo da -40 °C a +60 °C
Codice EAN 5022660314797
Codice doganale 39269097
PL1_Dim. Altezza 0.02m
PL1_Dim. Larghezza 0.15m
PL1_Dim. Lunghezza 0.18m
PL1_Peso 0.1097kg
PL1_Quantità 100
PL1_Tipologia confezione
PL1_Volume 0.00054
PL3_Dim. Altezza 0.192m
PL3_Dim. Larghezza 0.39m
PL3_Dim. Lunghezza 0.586m
PL3_Peso 11.495kg
PL3_Quantità 10000
PL3_Tipologia scatola
PL3_Volume 0.0439
PL4_Dim. Altezza 1.24m
PL4_Dim. Larghezza 0.8m
PL4_Dim. Lunghezza 1.2m
PL4_Peso 227.91kg
PL4_Quantità 180000
PL4_Tipologia pallet
PL4_Volume 1.19
Paese d'origine GB
org.mozilla.javascript.Undefined@0 EC000127
ETIM 8.0 Key EC000127
org.mozilla.javascript.Undefined@0 39121702
ETIM 9.0 Key EC000127
