Cable tie mount for adhesive use, Wmax=2.54mm, ∅2.8 mm, Adhesive, white, 100pcs.
Art.-Nr. 151-29002 | MB2.5A-PA66-WH Details

  • Simple to instal
  • Excellent security, particularly in areas of high vibration
  • Maximum surface area with adhesive to achieve high pull-off force
  • 4-way entry for cable tie for quicker and more flexible installation
Package size

Request your individual offer now

Application Where speed, simplicity and a firm fixing base are required these self adhesive clips are ideal. Particularly suitable for use in control cabinets, telecoms equipment or domestic appliances where the use of holes, screws, or nuts and bolts is impractical or undesirable.
Colour White (WH)
Fixation Method adhesive
For Ties T18
Material Polyamide 6.6 (PA66)
Maximum Static Load (lb/ft) 0.3lbf-ft
Mounting Screw Type Adhesive
PART DESCRIPTION MB2.5A-PA66-WH
Pack Cont. 100pcs.
Package Content packed in bag
Product Family MB-Series square design, self-adhesive
Product Group Cable tie mounts
Type MB2.5A
Height (H) 4.1mm
Length (L) 15.9mm
Load max. 1.334N
Strap Width max. (G) 0.1"
Strap Width max. (G) 2.54mm
Thickness of Adhesive (TA) nom. 0.031"
Thickness of Adhesive (TA) nom. 0.8mm
Width (W) 15.9mm
for Hole ∅ (FH) 2.8 mm
Adhesive Synthetic rubber with base of polyethylene foam
Adhesive Operating Temperature -18 °C to +66 °C
CE Certification No
CSA Certified No
Flammability UL 94 V2 (excluding adhesive)
Operating Temperature -40 °C to +85 °C
ROHS compliant Yes
Specifications
UL Listed (US and Canada) No
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
UL Recognized (US and Canada) No
UV-Stabilised No
Country of Origin US
GTIN-13 / EAN 4031026726526
Packaging 3 - Height (m) 0.212725m
Packaging 3 - Length (m) 0.51435m
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.0347
Packaging 3 - Width (m) 0.3175m
ETIM 7.0 Key EC000449
ETIM 8.0 Key EC000449
ETIM 9.0 Key EC000449
UNSPSC Key 39121717
