Fixing tie for hole (oval), outside serrated, ⌀4.0-45.0mm, black, 500pcs.
Art.-Nr. 156-03586
| S50ROS1DOP62x122-PP/PA66HIRHS-BK
|
Copied
- Pre-assembled 2-piece fixing tie with fir tree foot part
- Cable tie head can be moved after bundling
- Easy to assemble without the need for a tool
- Disc adjusts tie for pressure from various directions and minimises access of dust and dirt
- Fir tree foot part can be used for a variety of panel thicknesses
- Suitable for use within threaded holes
- DOP versions for oval holes feature anti-twist protection
Show more
Show less
Request quote
More products in this product group:
2-piece fixing ties with fir tree, with disc, for oval holes
| Application | Designed for securing and routing cables, pipes and hoses to panels, frames and other structures. The fir tree fixing enables push-in installation into oval holes, while the cable tie supports organised bundle routing and secure positioning in automotive and industrial applications. |
| Colour | Black (BK) |
| Description |
These two-piece fixings are supplied ready assembled and offer a simple and versatile method of bundling and fixing cables. The fir-tree base will easily push into pre-punched holes in panels or threaded, blind, holes and offers a very secure fixing. The two-piece design enables the head of the tie to be orientated to the required position to ease assembly, whilst the 'disc' on the top of the fir tree covers the hole and minimises the ingress of water and dirt. The outside serration design ensures gentle handling of sensitive cables and bundles, reducing the risk of damage during installation and maintenance With an anti-slip feature on the inside, the S50ROS prevents undesired lateral movement of cables and bundles, maintaining tidy and organized cable management within vehicles |
| Fixation Method | Fir Tree for oval holes |
| Identification Plate Position | none |
| Material | Polypropylene (PP), Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS) |
| Min.Tensile Strength | 185N |
| PART DESCRIPTION | S50ROS1DOP62x122-PP/PA66HIRHS-BK |
| Package Content | 500pcs. |
| Package Content packed in | bag |
| Product Family | S50ROS series with fixing element |
| Product Group | 2-piece fixing ties with fir tree, with disc, for oval holes |
| Releasable Closure (Yes/No) | No |
| Short Description | S50ROS cable tie with fixing element for oval holes 6.2 x 12.2 mm. |
| Tie Closure | plastic pawl |
| Type | S50ROS1DOP62x122 |
| Typical Application | Designed for securing and routing cables, pipes and hoses to panels, frames and other structures. The fir tree fixing enables push-in installation into oval holes, while the cable tie supports organised bundle routing and secure positioning in automotive and industrial applications. |
| Variant | Outside Serrated with AntiSlip Engraving |
| Weight/Unit | 0.0025kg |
| Bundle ⌀ | 4.0-45.0mm |
| Bundle ⌀ max. | 45.0mm |
| Bundle ⌀ min. | 4.0mm |
| Cable Tie Head Height (metric) | 7.5mm |
| Cable Tie Head Length (metric) | 8.3mm |
| Cable Tie Head Width (metric) | 8.95mm |
| Disc ⌀ | 16.0 x 21.0mm |
| Fixing Hole Shape | Oval |
| Height (H) | 1.3mm |
| Length (L) | 200.00mm |
| Panel Thickness | 0.6 - 6.0mm |
| Thickness (T) | 1.45mm |
| Width (W) | 4.90mm |
| for Hole ⌀ (FH) | 6.2 x 12.2 mm |
| for Panel Thickness min - max | 0.6 - 6 mm |
|
|
|
| Country of Origin | PL |
| Customs Number | 39269097 |
| GTIN-13 / EAN | 4031026752457 |
| Packaging 1 - Height (m) | 0.08m |
| Packaging 1 - Length (m) | 0.45m |
| Packaging 1 - Qty | 500 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.0144m³ |
| Packaging 1 - Weight (kg) | 1.279135kg |
| Packaging 1 - Width (m) | 0.4m |
| Packaging 3 - Height (m) | 0.368m |
| Packaging 3 - Length (m) | 0.584m |
| Packaging 3 - Qty | 4000 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.083m³ |
| Packaging 3 - Weight (kg) | 11.10388kg |
| Packaging 3 - Width (m) | 0.386m |
| Packaging 4 - Height (m) | 1.248m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 48000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.198m³ |
| Packaging 4 - Weight (kg) | 155.236kg |
| Packaging 4 - Width (m) | 0.8m |
