21/07/2025

Fixing tie to close hole, inside serrated, ⌀1.5-50.0mm, black, 3000
Art.-Nr. 156-03287 | T50RBHM8-PA66HIRHSUV/POM-BK |

Add to watchlist

Request your individual offer now

Request quote

Content

T50R 111-01566
Cable Ties impact modified
On my watchlist Add to watchlist

Please log in with your HellermannTyton account to use your personal watchlist.
Login / Register

Base Data

Colour	Black (BK)
Fixation Method	Blind Plug
Identification Plate Position	none
Material	Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV), Polyacetal (POM)
Min.Tensile Strength	225N
PART DESCRIPTION	T50RBHM8-PA66HIRHSUV/POM-BK
Package Content	3000
Package Content packed in	pack
Type	T50RBHM8
UV-Stabilised	Yes

Product Dimensions

⌀ D	0.3"
Bundle ⌀	1.5-50.0mm
Bundle ⌀ max.	50.0mm
Bundle ⌀ min.	1.5mm
Diameter (D)	7.62mm
Disc ⌀	13.5mm
Height (H)	15.75mm
Height (H2)	21.1mm
Hole Depth	11.0mm
Length (L)	202.0mm
Width (W)	7.6mm
for Hole ⌀ (FH)	8.0 mm

Downloads

Specifications

CE Certification	No
CSA Certified	No
Flammability	UL 94 HB
Halogen-free	Yes
Operating Temperature	-40 °C to +90 °C
ROHS compliant	Yes
Specifications
UL Listed (US and Canada)	No
UL Listed (US and Canada)	No
UL Recognized (US and Canada)	No
UL Recognized (US)	No

Logistics and Packaging

Country of Origin	MX
GTIN-13 / EAN	4031026734453
Packaging 1 - Qty	3000
Packaging 1 - Type	bag
Packaging 3 - Height (m)	0.219075m
Packaging 3 - Length (m)	0.6064m
Packaging 3 - Type	box
Packaging 3 - Volume (m³)	0.0529m³
Packaging 3 - Width (m)	0.3984625m

More Information

ETIM 7.0 Key	EC000046
ETIM 8.0 Key	EC000046
ETIM 9.0 Key	EC000046
UNSPSC Key	39121703
