Fixing tie for connector/for cable bundles, inside serrated, ⌀2-45mm, black, 500pcs.
Art.-Nr. 156-03251 | T50RCC11A-PA66HS/PA66HIRHS-BK |

Copied

    • Easy to assemble without a need for a tool
    • Preassembled cable tie with connector clip
    • Connector can be removed without damage
    • Rattle-free mounting
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application These two piece fixing ties with connector clips have been designed for electronic cables and cable sets used in the automotve industry. The connector are pushed onto the connector clip and hold firmly in place.
    Cable Tie Polyamide 6.6, heat stabilised (PA66HS)
    Colour Black (BK)
    Fixation Method Connector Clip
    Foot Part Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    Identification Plate Position none
    Material Polyamide 6.6, heat stabilised (PA66HS), Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    Min.Tensile Strength 225N
    PART DESCRIPTION T50RCC11A-PA66HS/PA66HIRHS-BK
    Package Content 500pcs.
    Package Content packed in bag
    Product Family Connector clip family
    Product Group 2-piece fixing tie with connector clip
    Releasable Closure (Yes/No) No
    Short Description 2-piece part, Connector clip adapter with bundling bar and cable tie, inside serrated,⌀2-45mm
    Tie Closure plastic pawl
    Type T50RCC11A
    Type of connection USCAR11
    Variant Inside Serrated
    Weight/Unit 0.002243kg
    Bundle ⌀ 2-45mm
    Bundle ⌀ max. 45mm
    Bundle ⌀ min. 2mm
    Height (H) 10.1mm
    Length (L) 202mm
    Width (W) 4.6mm
    Width (W2) 24.9mm
    ELV compliant (Article 4 - 2) YES
    Flammability UL 94 HB
    Halogen-free Yes
    Hazardous Goods No
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Specifications
    Country of Origin PL
    Customs Number 39269097
    GTIN-13 / EAN 4031026732473
    Packaging 1 - Height (m) 0.08m
    Packaging 1 - Length (m) 0.455m
    Packaging 1 - Qty 500
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.014742m³
    Packaging 1 - Weight (kg) 1.150635kg
    Packaging 1 - Width (m) 0.405m
    Packaging 3 - Height (m) 0.368m
    Packaging 3 - Length (m) 0.584m
    Packaging 3 - Qty 4000
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.083m³
    Packaging 3 - Weight (kg) 10.02508kg
    Packaging 3 - Width (m) 0.386m
    Packaging 4 - Height (m) 1.248m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 48000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.198m³
    Packaging 4 - Weight (kg) 141.288kg
    Packaging 4 - Width (m) 0.8m
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121703
