09/05/2024

Fixing tie for hole (oval), outside serrated, Ø1.8-50.0mm, brown, 2500pcs.
Art.-Nr. 157-00482 | T50ROSFTOVAL15R-PA46-BN |  Details

The fir tree mount cable tie is an all-in-one bundling and fastening solution that reduces costs and assembly time.

    • Bundling and fixing solution
    • Ideal combination of materials and design
    • Different positions of the fixing anchor are available to fit installation space
    • 1-Piece Fixing Tie with defined offset 12.5 and 25.0 mm
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Colour Brown (BN)
    Fixation Method Fir Tree for oval holes
    Identification Plate Position none
    Material Polyamide 4.6 (PA46)
    Pack Cont. 2500pcs.
    Package Content packed in bag
    PART DESCRIPTION T50ROSFTOVAL15R-PA46-BN
    Product Family with offset 12.5 and 25.0 mm
    Product Group 1-piece fixing ties with fir tree, with disc, with stand-off, for oval holes
    Releasable Closure (Yes/No) No
    Variant Outside Serrated
    Bundle Diameter max (metric) 50.0mm
    Bundle ∅ 1.8-50.0mm
    Bundle ∅ min. 1.8mm
    Disc ∅ 17.63 x 23.63mm
    Fixing Hole Shape Oval
    for Hole ∅ (FH) 6.2 x 12.2 mm, 6.5 x 12.5 mm, 6.5 x 13.0 mm, 7.0 x 12.0 mm
    for Panel Thickness min - max 0.6 - 6.8 mm
    for Panel Thickness min - max 0 - 0.3 "
    Height (H) 19.85mm
    Length (L) 227.0mm
    Length (L2) 15.0mm
    Min.Tensile Strength 220N
    Offset Length 15.0mm
    Panel Thickness max. 0.6 - 6.75mm
    Width (W) 23.6mm
    CE Certification No
    Flammability UL 94 V2
    Operating Temperature -40 °C to +135 °C, (+140 °C, 500 h)
    Specifications
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UV-Stabilised No
    Country of Origin US
    GTIN-13 / EAN 4031026634388
    Packaging 1 - Weight (kg) 2.471kg
    Packaging 3 - Height (m) 0.37465m
    Packaging 3 - Length (m) 0.59055m
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0646m³
    Packaging 3 - Width (m) 0.2921m
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121717
    Show all
    Cable holder Cable holder

    Cable holder

    Looking for a secure way to fasten cables or wires? Our plastic cable holders are easy to install and suitable for almost any application. Learn more...

    Cable holder >
    Art.-Nr.: 157-00482 Details My watchlist Contact
    Base Data Product Dimensions Specifications Logistics and Packaging Downloads
