01/07/2026

Lacing tape, Flat, braided, 113N, -55 °C to +175 °C, black, L=500m


Art.-Nr. 174-00024

| LTHT2E4BK-PET-BK

 |

Copied
  • High tensile strength
  • Vinyl chloride surface finishing provides good abrasion resistance

Colour Black (BK)
Fixation Method Others
Identification Plate Position none
Material Polyester (PET)
Min.Tensile Strength 113N
PART DESCRIPTION LTHT2E4BK-PET-BK
Package Content 500m
Package Content packed in reel
Product Family Lacing tape LTHT2E4BK
Product Group Lacing tape made of polyester
Releasable Closure (Yes/No) Yes
Short Description Lacing tape 500 m, 1.29-1.75 mm, PET, black
Type LTHT2E4BK
Variant Endless
Weight/Unit 0.0006kg
Length (L) 500m
Thickness (T) 0.24-0.36mm
Weight 0.6g/m
Width (W) max. 1.75mm
Width (W) min. 1.29mm
Curing Temperature -55 °C to +175 °C
ELV compliant (Article 4 - 2) Yes
Finish E = Vinyl
Hazardous Goods No
Lacing Shape Flat, braided
Operating Temperature -55 °C to +175 °C
ROHS compliant Yes
Specifications
Specifications A-A-52081, NSA8420
Surface Finishing Shortcut E
Country of Origin FR
Customs Number 58081000
GTIN-13 / EAN 4031026437439
Packaging 1 - Height (m) 0.26m
Packaging 1 - Length (m) 0.51m
Packaging 1 - Qty 500
Packaging 1 - Type reel
Packaging 1 - Volume (m³) 0.025194
Packaging 1 - Weight (kg) 0.3kg
Packaging 1 - Width (m) 0.19m
Packaging 3 - Height (m) 0.145m
Packaging 3 - Length (m) 0.38m
Packaging 3 - Qty 9000
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.0209
Packaging 3 - Weight (kg) 5.76kg
Packaging 3 - Width (m) 0.38m
Packaging 4 - Height (m) 1.304m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 432000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.252
Packaging 4 - Weight (kg) 298.48kg
Packaging 4 - Width (m) 0.8m
Reel Length 500m
ETIM 7.0 Key EC000046
ETIM 8.0 Key EC000046
ETIM 9.0 Key EC000046
