Lacing tape 500 m x 1.52 mm, PET, black
Art.-Nr. 174-00024 | LTHT2E4BK-PET-BK |  Details

Lacing cord LTHT2E4BK.

    • High tensile strength
    • Vinyl chloride surface finishing provides good abrasion resistance
    Add to watchlist

    Request your individual offer now

     Request quote
    Colour Black (BK)
    Fixation Method Others
    Identification Plate Position none
    Material Polyester (PET)
    Pack Cont. 500m
    Package Content packed in reel
    PART DESCRIPTION LTHT2E4BK-PET-BK
    Product Family Lacing tape LTHT2E4BK
    Product Group Lacing tape made of polyester
    Releasable Closure (Yes/No) Yes
    Short Description Lacing tape 500 m x 1.52 mm, PET, black
    Variant Endless
    Min.Tensile Strength 113N
    Thickness (T) 0.3mm
    Thickness (T) 0.27-0.43mm
    Weight 0.6g/m
    Weight/Unit 0.0006kg
    Width (W) 1.52mm
    Width (W) max. 1.67mm
    Width (W) min. 1.37mm
    Curing Temperature -67 °C to +177 °C
    ELV compliant (Article 4 - 2) YES
    Finish E = Vinyl
    Hazardous Goods No
    Lacing Shape Flat, braided
    Operating Temperature -67 °C to +177 °C
    Specifications
    Specifications A-A-52081, NSA8420
    Surface Finishing Shortcut E
    Country of Origin FR
    Customs Number 58081000
    GTIN-13 / EAN 4031026437439
    Packaging 1 - Height (m) 0.26m
    Packaging 1 - Length (m) 0.51m
    Packaging 1 - Qty 500
    Packaging 1 - Type reel
    Packaging 1 - Volume (m³) 0.02519m³
    Packaging 1 - Weight (kg) 0.3kg
    Packaging 1 - Width (m) 0.19m
    Packaging 3 - Height (m) 0.145m
    Packaging 3 - Length (m) 0.38m
    Packaging 3 - Qty 9000
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0209m³
    Packaging 3 - Weight (kg) 5.76kg
    Packaging 3 - Width (m) 0.38m
    Packaging 4 - Height (m) 1.304m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 432000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.252m³
    Packaging 4 - Weight (kg) 297.48kg
    Packaging 4 - Width (m) 0.8m
    Reel Length 500m
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
