Connector clip, black, 500pcs.
Art.-Nr. 151-02550 | CC19SFT7-PA66HIRHS-BK |

Copied

    • Connector easily installed by simply pushing into place
    • Connection can be released (non-destructive)
    • Arrowhead locks into place for secure fixing at all times
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application The Connector Clips used here have been designed for electronic cables and cable sets used in the automotive industry. These parts are related to a connector and then secured to a surface depending on the requirement
    Colour Black (BK)
    Fixation Method arrowhead
    Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    PART DESCRIPTION CC19SFT7-PA66HIRHS-BK
    Package Content 500pcs.
    Package Content packed in bag
    Type CC19SFT7
    Weight/Unit 0.00093kg
    Height (H) 17.4mm
    Length (L) 21.4mm
    Panel Thickness max. 2.3 - 3.0mm
    Width (W) 6.3mm
    for Hole ⌀ (FH) 7.0 - 7.2 mm
    for Panel Thickness min - max 2.3 - 3 mm
    ELV compliant (Article 4 - 2) YES
    Hazardous Goods No
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Specifications
    Country of Origin CN
    Customs Number 39269097
    GTIN-13 / EAN 4031026612256
    Packaging 3 - Qty 4000
    Packaging 3 - Type carton
    Packaging 3 - Weight (kg) 3.72kg
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 80000
    Packaging 4 - Type pallet
    Packaging 4 - Weight (kg) 95.4kg
    Packaging 4 - Width (m) 0.8m
    ETIM 7.0 Key EC000449
    ETIM 8.0 Key EC000449
    ETIM 9.0 Key EC000449
    UNSPSC Key 31162305
