Cable clip for stud
Art.-Nr. 151-03590 | DLC26M8-PA66HIRHSUV-BK

Copied
34142737

    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application
    Colour Black (BK)
    Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
    PART DESCRIPTION DLC26M8-PA66HIRHSUV-BK
    Package Content 1000pcs.
    Package Content packed in box
    Product Family Locking clamp with M8 stud mount, multi paralllel routing
    Product Group Fixing elements for tubes and harnesses
    Type DLC26M8
    UV-Stabilised Yes
    CE Certification No
    CSA Certified No
    Operating Temperature -40 °C to +105 °C
    Country of Origin MX
    GTIN-13 / EAN 4031026677033
    Packaging 1 - Type bag
    Packaging 3 - Height (m) 0.1730375m
    Packaging 3 - Length (m) 0.57785m
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0349m³
    Packaging 3 - Width (m) 0.34925m
    ETIM 7.0 Key EC000127
    ETIM 8.0 Key EC000127
    ETIM 9.0 Key EC000127
    UNSPSC Key 31162305
