Ratchet O-Clamp
Art.-Nr. 151-04175 | SGDROC15.5-20FT6.5LG-PA66HIRHSUV/TPE-BK |

Copied

    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Colour Black (BK)
    Fixation Method Fir Tree
    Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV), Thermoplastic Elastomer (TPE)
    Min.Tensile Strength 445N
    PART DESCRIPTION SGDROC15.5-20FT6.5LG-PA66HIRHSUV/TPE-BK
    Package Content 400
    Package Content packed in box
    Product Group Ratchet O-Clamp
    Type SGDROC15.5-20FT6.5LG
    UV-Stabilised Yes
    Weight/Unit 0.014186kg
    Bundle ⌀ 15.5-20.0mm
    Bundle ⌀ max. 20.0mm
    Bundle ⌀ min. 15.5mm
    Height (H) 58.1mm
    Length (L) 112.2mm
    Panel Thickness 0.6 - 6.0mm
    Width (W) 20.5mm
    for Hole ⌀ (FH) 6.1 - 7.0 mm
    CE Certification No
    CSA Certified No
    Flammability UL 94 HB
    Halogen-free Yes
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Reusable (Yes/No) Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US) No
    UL Recognized (US and Canada) No
    UL Recognized (US) No
    Country of Origin MX
    GTIN-13 / EAN 4031026739229
    Packaging 1 - Qty 400
    Packaging 1 - Weight (kg) 5.6744405kg
    Packaging 3 - Height (m) 0.209549999999999m
    Packaging 3 - Length (m) 0.606425m
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0504m³
    Packaging 3 - Width (m) 0.39688m
    ETIM 7.0 Key EC000127
    ETIM 8.0 Key EC000127
    ETIM 9.0 Key EC000127
    UNSPSC Key 39121705
