RCAINSERT : RCAINSERT
Art.-Nr. 854-44258 | RCAINSERT Details

  • Standard keystone style interface
  • RJ45 terminated to a 110 IDC PCB connector
  • Jack life a maximum of 1,000 insertions
  • Contact set constructed of phosphor bronze material with 50 micro-inch gold plating
  • Components manufactured from UL94V-0 thermoplastic material
  • Unique strain relief design secures cable terminations
  • Innovative crosstalk cancellation technology – 10 internal contacts (two extra to cancel out crosstalk) and 8 external contacts in standard configuration to accept industry standard patch cords
  • Staggered contacts provide superior performance
  • Configured with both 568A and 568B wiring schemes
  • IDC accepts 22-26 AWG solid twisted-pair cable
  • Available in 12 colors to match any faceplate or color coding identification
  • Palm tool available for easy on-site installation
  • RJ45 jacks are factory tested 200 times with an RJ11 plug (4P or 6P) to ensure there is no damage to the contacts.
  • Each jack is individually tested three times to ensure quality performance
  • IDC is factory tested to 50 terminations
Show more

Request your individual offer now

Country of Origin TW
ETIM 8.0 Key EC001121
ETIM 9.0 Key EC001121
UNSPSC Key 43223301
