FT13-PA66HIRHS-BK


Art.-Nr. 151-01307

| FT13-PA66HIRHS-BK

 |

Copied

Colour Black (BK)
Fixation Method Fir Tree
Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
PART DESCRIPTION FT13-PA66HIRHS-BK
Package Content 250pcs.
Package Content packed in bag
Type FT13
Weight/Unit 0.003369kg
Length (L) 33.6mm
for Hole ⌀ (FH) 12.8 - 13.2 mm
for Panel Thickness min - max 0.7 - 10 mm
ELV compliant (Article 4 - 2) Yes
Hazardous Goods No
ROHS compliant Yes
Specifications
Country of Origin CN
Customs Number 39269097
GTIN-13 / EAN 4031026510705
Packaging 1 - Height (m) 0.1m
Packaging 1 - Length (m) 0.26m
Packaging 1 - Qty 250
Packaging 1 - Type bag
Packaging 1 - Volume (m³) 0.0065
Packaging 1 - Weight (kg) 0.842251kg
Packaging 1 - Width (m) 0.25m
Packaging 3 - Height (m) 0.22m
Packaging 3 - Length (m) 0.57m
Packaging 3 - Qty 2500
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.0489
Packaging 3 - Weight (kg) 9.12751kg
Packaging 3 - Width (m) 0.39m
Packaging 4 - Height (m) 1.244m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 50000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.194
Packaging 4 - Weight (kg) 204.55kg
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC000449
ETIM 8.0 Key EC000449
ETIM 9.0 Key EC000449
UNSPSC Key 39121717
