Cable tie inside serrated, 100.0x2.5mm, ∅5.0-22.0mm, blue, 100pcs.
Art.-No. 111-00659 | T18R-E/TFE-BU Details

  • Blue cable tie offering high chemical resistance
  • Suitable for applications with temperatures up to +170 °C
  • Resistant to radioactivity and UV light
  • E/TFE is a non hydroscopic material, no moisture absorption
  • Complying with UL94 V0 requirements
Show more

Request your individual offer now

e-Learning
Application T-Series cable ties for bundling and securing of cables, pipes and hoses. These cable ties can be used for nearly all kind of applications.
Colour Blue (BU)
Identification Plate Position none
Material Ethylene Tetrafluoroethylene (E/TFE)
PART DESCRIPTION T18R-E/TFE-BU
Pack Content 100pcs.
Package Content packed in bag
Product Family T-Series in E/TFE (Tefzel®) blue
Product Group Cable Ties for higher chemical resistance and temperatures up to +170°C
Releasable Closure (Yes/No) No
Tie Closure plastic pawl
Type T18R
Variant Inside Serrated
Bundle Diameter max (metric) 22.0mm
Bundle ∅ min. 5.0mm
Cable Tie Head Length (metric) 4.8mm
Cable Tie Head Width (metric) 4.45mm
Height (H) 3.7mm
Length (L) 100.0mm
Min.Tensile Strength 80N
Strap Width max. (G) 0.18"
Thickness (T) 1.2mm
Width (W) 2.5mm
CE Certification No
CSA Certified No
ELV compliant (Article 4 - 2) YES
Flammability UL 94 V0
Hazardous Goods No
Operating Temperature -80 °C to +170 °C
ROHS compliant Yes
Specifications
Specifications ANSI/UL 1565, ANSI/UL 62275
UL Listed (US and Canada) No
UL Listed (US and Canada) No
UL OCD link Link
UL Recognized (US and Canada) Yes
UL Recognized (US and Canada) No
UL-File Number E64962
UV-Stabilised No
GTIN-13 / EAN 4944387123418
Packaging 1 - Height (m) 0.01m
Packaging 1 - Length (m) 0.17m
Packaging 1 - Qty 100
Packaging 1 - Type bag
Packaging 1 - Volume (m³) 0.00017
Packaging 1 - Weight (kg) 0.053kg
Packaging 1 - Width (m) 0.1m
Packaging 3 - Height (m) 0.25m
Packaging 3 - Length (m) 0.44m
Packaging 3 - Qty 25000
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.0341
Packaging 3 - Weight (kg) 12.8kg
Packaging 3 - Width (m) 0.31m
Packaging 4 - Height (m) 1.144m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 600000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.098
Packaging 4 - Weight (kg) 328.2kg
Packaging 4 - Width (m) 0.8m
UNSPSC Key 39121703
