Cable clip for hole (oval), T=0.6-6.5mm, ⌀6.2 x 12.2 mm/6.5 x 12.5 mm, Dmin=18.0mm, Dmax=22.0mm
Art.-No. 151-02123 | PC3OVAL-PA66HIRHS-BK |

Copied

    • For fixing and bundling convoluted tubes and pipes
    • Suitable for nearly every application
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application These clips offer fast and easy bundling of convuluted tubes and pipes, especially for the automotive industry.
    Colour Black (BK)
    Fixation Method Fir Tree
    Key product features for multiple routing, for faster processing, lockable
    Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    PART DESCRIPTION PC3OVAL-PA66HIRHS-BK
    Pack Cont. 1000pcs.
    Package Content packed in carton
    Type PC3OVAL
    Attach to ⌀ 18.0, 22.0
    Bundle ⌀ max. 22.0mm
    Bundle ⌀ min. 18.0mm
    Height (H) 69.6mm
    Length (L) 91.5mm
    Panel Thickness max. 0.6-6.5mm
    Width (W) 17.6mm
    for Hole ⌀ (FH) 6.2 x 12.2 mm, 6.5 x 12.5 mm, 6.5 x 13.0 mm, 7.0 x 12.0 mm
    for Panel Thickness min - max 0.6 - 6.5 mm
    ELV compliant (Article 4 - 2) YES
    Hazardous Goods No
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Specifications
    GTIN-13 / EAN 4031026601465
    UNSPSC Key 31162906
