Cable tie mount with pipe/tube holder/for screw fixation, ⌀8.12 mm, black, 500pcs.
Art.-No. 133-00998 | HC3A-PA66HIRGF13-BK

Copied
10949987
HC3A
Each mount has two pawls for easy pre-installation on a threaded fastener prior to securing with a mechanical fastener.
957457
Clip includes an internal rib that spans the inside of the bracket to fit securely into the profile of the tubing to prevent lateral movement and slipping of the tubing.

    • Separates and secures bundles avoiding abrasion.
    • Designed to handle both convoluted tubing and bundles not covered in convoluted tubing.
    • Available in a variety of sizes and colors to be easily identified.
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads e-Learning
    Colour Black (BK)
    Key product features for multiple routing, vibration absorbing, lockable
    Material Polyamide 6.6, high impact modified, glass-fiber reinforced (PA66HIRGF13)
    No. of bundles 3
    PART DESCRIPTION HC3A-PA66HIRGF13-BK
    Pack Content 500pcs.
    Package Content packed in pack
    Product Family multi parallel routing
    Product Group Fixing elements for tubes and harnesses
    Type HC3A
    UV-Stabilised No
    Variant Separators
    ⌀ max. 1. loop 24.39mm
    ⌀ max. 2. loops 24.39mm
    Bundle ⌀ max. 24.3mm
    Bundle ⌀ min. 24.39mm
    Height (H) 34.94mm
    Length (L) 107.86mm
    Width (W) 27.94mm
    for Hole ⌀ (FH) 8.12 mm
    CE Certification No
    CSA Certified No
    ELV compliant (Article 4 - 2) Yes
    Hazardous Goods No
    Operating Temperature -40 °C to +125 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US) No
    UL Recognized (US and Canada) No
    UL Recognized (US) No
    GTIN-13 / EAN 4031026455037
    Packaging 1 - Height (m) 0.27m
    Packaging 1 - Length (m) 0.51m
    Packaging 1 - Qty 500
    Packaging 1 - Type bag
    Packaging 1 - Volume (m³) 0.0598995m³
    Packaging 1 - Weight (kg) 10.786001kg
    Packaging 1 - Width (m) 0.435m
    Packaging 2 - Type carton
    Packaging 3 - Height (m) 0.37465m
    Packaging 3 - Length (m) 0.59055m
    Packaging 3 - Qty 500
    Packaging 3 - Type carton
    Packaging 3 - Volume (m³) 0.0646m³
    Packaging 3 - Weight (kg) 12.1kg
    Packaging 3 - Width (m) 0.2921m
    Packaging 4 - Height (m) 1.12m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 12000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.075m³
    Packaging 4 - Weight (kg) 90.606kg
    Packaging 4 - Width (m) 0.8m
    UNSPSC Key 39121705
