Cable tie mount for stud, black, 200pcs.
Art.-No. 156-02425 | SFSFTP Set-PA6GF30/PA66HIRHS-BK |  Details

From left to right: Bold Nut HDBN16, SFTP-Spacer and at the front: SFTP-Fixing.

    • Bundles are securely fixed with cable ties due to H-design of plate
    • Plate can be fixed either with SFTP-Spacer for holes or bolt nut HDBN16 for M16 stud
    • Very robust and vibration resistant fixing method for lead frames
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application This SFTP-Heavy Duty fixing plate is used to run and fix cables to lead frames which can be found at railway, truck and agricultural vehicle construction. The cable harness is fixed with X120R tie onto the plate. The mounted plate can be fixed with the Rivet mount if a whole is valid at the frame. Or you can use the Bold Nut HDBN16 if a M16 stud is available. Both methods allow for a simple click and the harness is quick and vibration resistant applied to the lead frame.
    Colour Black (BK)
    Key product features vibration absorbing
    Material Polyamide 6, glass-fibre reinforced (PA6GF30), Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    Pack Content 200pcs.
    Package Content packed in bag
    PART DESCRIPTION SFSFTP Set-PA6GF30/PA66HIRHS-BK
    Product Family SFTP-Series
    Product Group Fastening plate and rivet mount for heavy duty applications
    Height (H) 84.7mm
    Width (W) 16.6mm
    ELV compliant (Article 4 - 2) YES
    Hazardous Goods No
    Specifications
    GTIN-13 / EAN 4031026603261
    Packaging 3 - Height (m) 0.204m
    Packaging 3 - Length (m) 0.591m
    Packaging 3 - Qty 200
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.048m³
    Packaging 3 - Weight (kg) 11.8076kg
    Packaging 3 - Width (m) 0.398m
    Packaging 4 - Height (m) 1.235m
    Packaging 4 - Length (m) 1.2m
    Packaging 4 - Qty 4000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.186m³
    Packaging 4 - Weight (kg) 257.152kg
    Packaging 4 - Width (m) 0.8m
    UNSPSC Key 39121717
