15/06/2021

Cable Ties without serration in flexible TPU : SRT58028

Cable Ties without serration in flexible TPU 580x28.0 blackArticle number: 115-28589

Features

  • Elastic and flexible cable ties with rounded and smooth edges
  • Releasable and reusable
  • Double slotted head with fixation pawl
  • Flexibility ensures steady and evenly distributed pressure
  • Tight fixation even in vertical position: prevent sliding down or loosing bundle
  • Suitable for moving elements and vibrating applications like windmills, machines, robotics, pulsating tubing and conduits
  • Ideal use for temporarily fixation for presentations, concerts, theatres, exhibitions
  • Long lifetime when used indoor
  • Remains flexible even at cold temperatures (-20 °C)

Certifications & Approvals

Application

The soft, flexible material makes these ties particulary suitable for use on sensitive wires, for instance fibre-optic cables. Additionally they are suitable for moving elements and vibrating applications. The double slotted head allows for parallel bundling.

Colour Black (BK)
Identification Plate Position none
Pack Content 10pcs.
Package Quantity per pcs.
PART DESCRIPTION SRT58028-TPU-BK
Product Family SRT-Series for industry quantities
Product Group Cable Ties without serration in flexible TPU
Releasable Closure (Yes/No) Yes
Short Description The elasticity of the tie means that in applications such as securing trees, it is not necessary to loosen the tie and re-tighten it as frequently as with other products - the tie will grow with the tree.
Tie Closure ladder style
Variant No Serration
Bundle ∅ max. 150mm
Length (L) 580mm
Min.Tensile Strength 360N
Thickness (T) 3.4mm
Width (W) 28.0mm
ELV compliant (Article 4 - 2) YES
Flammability UL 94 HB
Halogenfree Yes
Hazardous good No
Material Thermoplastic Polyurethane (TPU)
Material TPU
Operating Temperature - °C -40 °C to +85 °C
Specifications
GTIN-13 / EAN 4031026108599
Packaging 1 - Height (m) 0.03m
Packaging 1 - Length (m) 0.61m
Packaging 1 - Qty 10
Packaging 1 - Type bag
Packaging 1 - Volume (m³) 0.00256
Packaging 1 - Weight (kg) 0.582kg
Packaging 1 - Width (m) 0.14m
Packaging 3 - Height (m) 0.28m
Packaging 3 - Length (m) 0.79m
Packaging 3 - Qty 200
Packaging 3 - Type carton
Packaging 3 - Volume (m³) 0.0664
Packaging 3 - Weight (kg) 12.14kg
Packaging 3 - Width (m) 0.3m
Packaging 4 - Height (m) 0.984m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 2400
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 0.945
Packaging 4 - Weight (kg) 166.68kg
Packaging 4 - Width (m) 0.8m
