Fixing tie for hole (round), inside serrated, Ø5.0-55.0mm, black, 1000pcs.
Art.-No. 156-01610 | T120SFT12SET-PA66HS/PA66HIRHSUV-BK |  Details

Unassembled set allows user to connect the cable tie either perpendicular or inline with the oval mounting hole.

    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Cable Tie Polyamide 6.6, heat stabilised (PA66HS)
    Colour Black (BK)
    Fixation Method Fir tree for round holes
    Identification Plate Position none
    Material Polyamide 6.6, heat stabilised (PA66HS), Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
    PART DESCRIPTION T120SFT12SET-PA66HS/PA66HIRHSUV-BK
    Pack Content 1000pcs.
    Package Content packed in carton
    Releasable Closure (Yes/No) No
    Tie Closure plastic pawl
    Type T120SFT12SET
    Variant Inside Serrated
    Bundle Diameter max (metric) 55.0mm
    Bundle ∅ min. 5.0mm
    Height (H) 29.70mm
    Height (H2) 19.0mm
    Length (L) 229.0mm
    Min.Tensile Strength 535N
    Panel Thickness 0.02 - 0.43"
    Panel Thickness max. 0.6 - 11.0mm
    Panel Thickness max. (imperial) 0.43"
    Panel Thickness min. (imperial) 0.02"
    Thickness (T) 1.8mm
    Width (W) 7.6mm
    Width (W2) 0.80"
    Width (W2) 20.40mm
    for Hole ∅ (FH) 11.6 - 12.4 mm
    for Panel Thickness min - max 0.6 - 11 mm
    for Panel Thickness min - max 0 - 0.4 "
    CE Certification No
    CSA Certified No
    Flammability UL 94 HB
    Operating Temperature -40 °C to +110 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US and Canada) No
    UV-Stabilised Yes
    GTIN-13 / EAN 4031026561974
    Packaging 3 - Height (m) 0.212725m
    Packaging 3 - Length (m) 0.51435m
    Packaging 3 - Type carton
    Packaging 3 - Volume (m³) 0.0347m³
    Packaging 3 - Width (m) 0.3175m
    UNSPSC Key 39121703
