Fixing tie for hole (oval), inside serrated, ⌀5.0-50.0mm, orange/black, 2000pcs.
Art.-No. 156-04034
| T50RFT9X17A2SET-PA66HIRHS/PA66HIRHSUV-OG/BK
|
Copied
Request quote
| Cable Tie | Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS) |
| Colour | Orange (OG), High Voltage (HV), Black (BK) |
| Fixation Method | Fir Tree for oval holes |
| Identification Plate Position | none |
| Material | Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS), Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV) |
| Min.Tensile Strength | 225N |
| PART DESCRIPTION | T50RFT9X17A2SET-PA66HIRHS/PA66HIRHSUV-OG/BK |
| Pack Content | 2000pcs. |
| Package Content packed in | pack |
| Releasable Closure (Yes/No) | No |
| Tie Closure | plastic pawl |
| Type | T50RFT9X17A2SET |
| UV-Stabilised | Yes |
| Variant | Inside Serrated |
| Bundle ⌀ max. | 50.0mm |
| Bundle ⌀ min. | 5.0mm |
| Disc ⌀ | 1.0" |
| Disc ⌀ | 25.5mm |
| Fixing Hole Shape | Oval |
| Height (H) | 1.2mm |
| Height (H2) | 20.3mm |
| Hole Depth | 0.6mm |
| Hole Depth | 5.5mm |
| Length (L) | 202.0mm |
| Panel Thickness | 0.02 - 0.22" |
| Panel Thickness | 0.6 - 5.5mm |
| Panel Thickness max. (imperial) | 0.22" |
| Panel Thickness min. (imperial) | 0.02" |
| Strap Width max. (G) | 0.21" |
| Thickness (T) | 1.2mm |
| Width (W) | 4.6mm |
| Width (W2) | 0.79" |
| Width (W2) | 20.3mm |
| for Hole ⌀ (FH) | 9.0 x 17.0 mm |
| for Panel Thickness min - max | 0.6 - 5.5 mm |
| for Panel Thickness min - max | 0 - 0.2 " |
