Fixing tie with pipe/tube holder, inside serrated, ⌀23.0-29.0mm, black, 1000pcs.
Art.-No. 156-01821 | T50RMOC26SAD-SET-PA66HIRHSUV-BK |

Copied
The bi-directional saddle design allows the bundles to be coupled parallel or perpendicular to one another.

    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Cable ⌀ max 50.0mm
    Cable ⌀ min 1.5mm
    Colour Black (BK)
    Fixation Method Omega Clip
    Identification Plate Position none
    Key product features for multiple routing, removable
    Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
    Min.Tensile Strength 225N
    PART DESCRIPTION T50RMOC26SAD-SET-PA66HIRHSUV-BK
    Pack Content 1000pcs.
    Package Content packed in pack
    Product Group 2-Piece Fixing Ties with Pipe Clip
    Releasable Closure (Yes/No) No
    Tie Closure plastic pawl
    Type T50RMOC26SAD-SET
    UV-Stabilised Yes
    Variant Inside Serrated
    Bundle ⌀ max. 29.0mm
    Bundle ⌀ min. 23.0mm
    Bundle Diameter Nom. (ND) 26.0 mm
    Depth (D) 12.0mm
    Height (H) 47.1mm
    Length (L) 34.5mm
    Length (L2) 23.2mm
    CE Certification No
    CSA Certified No
    Flammability UL 94 HB
    Halogen-free Yes
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US) No
    GTIN-13 / EAN 4031026592800
    Packaging 1 - Type bag
    Packaging 1 - Weight (kg) 204.15kg
    Packaging 3 - Height (m) 0.20479m
    Packaging 3 - Length (m) 0.5159375m
    Packaging 3 - Type carton
    Packaging 3 - Volume (m³) 0.0332m³
    Packaging 3 - Width (m) 0.314325m
    UNSPSC Key 39121702
    Cable holder Cable holder

    Cable holder

    Looking for a secure way to fasten cables or wires? Our plastic cable holders are easy to install and suitable for almost any application. Learn more...

    Cable holder >
    Art.-No.: 156-01821 Contact
    Base Data Product Dimensions Specifications Logistics and Packaging Downloads
