Fixing tie with pipe/tube holder, Ø10.0-14.0mm, black, 1000pcs.
Art.-No. 156-02594 | T50SMVCLOC10-14-PA66HIRHSUV-BK Details

  • Fixing Clip offers full 360° rotation
  • Inside serrated cable tie
  • Routed cable can move in any direction in relation to the fixing point
  • Automatic closure clip

Request your individual offer now

Application The fasteners interconnect two different bundles of goods, of various size and type. The mobility of the fixing provides a secure grip and protects the cables or bundles, even in difficult conditions.
Cable ∅ max 50.0mm
Cable ∅ min 2.0mm
Colour Black (BK)
Fixation Method Omega Clip
Identification Plate Position none
Key product features lockable, rotatable
Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
Pack Content 1000pcs.
Package Content packed in carton
PART DESCRIPTION T50SMVCLOC10-14-PA66HIRHSUV-BK
Product Group 2-piece fixing ties with pipe clip
Attach to Diameter 0.39 - 0.55 "
Attach to Ø 10.0 - 14.0mm
Bundle Diameter max (metric) 14.0mm
Bundle Diameter Nom. (ND) 10.0 mm - 14.0 mm
Bundle ∅ min. 10.0mm
Depth (D) 12.0mm
Height (H) 27.4mm
Length (L) 210.0mm
Length (L2) 20.6mm
Min.Tensile Strength 225N
Width (W) 12.0mm
CE Certification No
CSA Certified No
Flammability UL 94 HB
Halogen-free Yes
Operating Temperature -40 °C to +110 °C
Specifications
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
UV-Stabilised (Yes/No) Yes
GTIN-13 / EAN 4031026717906
Packaging 1 - Weight (kg) 202.8kg
Packaging 3 - Height (m) 0.22225m
Packaging 3 - Length (m) 0.60325m
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.0532
Packaging 3 - Weight (kg) 5.26kg
Packaging 3 - Width (m) 0.396875m
UNSPSC Key 39121702
