Bundling clip for hole (round), L=75.0mm, silver, 2000pcs.
Art.-No. 151-02177
| BCATC4-PPS-SR
|
Copied
| Application | Bundling clips are designed to provide simple and easy methods of securing cable bundles, hoses, or pipes. They are fastened onto the tape bar using bundle or cable ties. The different fixing orientations allow tape clips to be used with a wide range of panel thicknesses and hole diameters. Standard bundling clips are available as well as standoff and stud mount versions. |
| Colour | Silver (SR) |
| Fixation Method | arrowhead |
| Material | Polyphenylene Sulfide (PPS) |
| PART DESCRIPTION | BCATC4-PPS-SR |
| Pack Content | 2000pcs. |
| Package Content packed in | pack |
| Type | BCATC4 |
| UV-Stabilised | No |
| Bundling Bar Length | 2.95" |
| Bundling Bar Length | 75.0mm |
| Height (H) | 27.34mm |
| Length (L) | 75.0mm |
| Panel Thickness | 0.53 - 0.59" |
| Panel Thickness max. | 13.5 - 15.0mm |
| Panel Thickness max. (imperial) | 0.59" |
| Panel Thickness min. (imperial) | 0.53" |
| Width (W) | 11.43mm |
| for Hole ⌀ (FH) | 11.7 - 13.0 mm |
| for Panel Thickness min - max | 13.5 - 15 mm |
Download
|
|
|
| GTIN-13 / EAN | 4031026587950 |
| Packaging 1 - Height (m) | 0.225m |
| Packaging 1 - Length (m) | 0.505m |
| Packaging 1 - Qty | 2000 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.035791875m³ |
| Packaging 1 - Weight (kg) | 6.672001kg |
| Packaging 1 - Width (m) | 0.315m |
| Packaging 3 - Height (m) | 0.219075m |
| Packaging 3 - Length (m) | 0.6064m |
| Packaging 3 - Qty | 2000 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.0529m³ |
| Packaging 3 - Weight (kg) | 7.78kg |
| Packaging 3 - Width (m) | 0.3984625m |
| Packaging 4 - Height (m) | 1.269m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 24000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.218m³ |
| Packaging 4 - Weight (kg) | 109.824kg |
| Packaging 4 - Width (m) | 0.8m |
