Bundling clip for hole (round), L=55.0mm, black, 500pcs.
Art.-No. 155-11601
| BCSFT6.5 16-3MD-PA66HIRHS-BK
|
Copied
- Simple installation, tool-free
- Defined distance to the mounting hole
Request your individual offer now
Request quote
More products in this product group:
| Application | These cable clips are particularly popular in the automotive industry, as cable harnesses can be easily installed in different areas of the vehicle. Due to their flat and lightweight design, they are an optimal solution for limited spaces. |
| Anti rotation (Yes / No) | NO |
| Colour | Black (BK) |
| Fixation Method | arrowhead |
| Key product features | sealed |
| Material | Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS) |
| PART DESCRIPTION | BCSFT6.5 16-3MD-PA66HIRHS-BK |
| Pack Content | 500pcs. |
| Package Content packed in | pack |
| Product Family | Bundling clips with arrowhead, sealed |
| Product Group | Bundling clips with arrowhead, sealed |
| Type | BCSFT6.5 16-3MD |
| UV-Stabilised | No |
| Wings on clip base (Yes / No) | YES |
| Bundling Bar Length | 2.17" |
| Bundling Bar Length | 55.0mm |
| Disc ⌀ | 0.63" |
| Disc ⌀ | 16.0mm |
| Fixing Hole Shape | Circular |
| Height (H) | 14.0mm |
| Length (L) | 55.0mm |
| Panel Thickness | 0.06 - 0.12" |
| Panel Thickness | 1.5 - 3.0mm |
| Panel Thickness max. (imperial) | 0.12" |
| Panel Thickness min. (imperial) | 0.06" |
| Width (W) | 8.0mm |
| for Hole ⌀ (FH) | 6.3 - 6.7 mm |
| for Panel Thickness min - max | 1.5 - 3 mm |
Download
|
|
|
| GTIN-13 / EAN | 4031026208770 |
| Packaging 1 - Height (m) | 0.06m |
| Packaging 1 - Length (m) | 0.22m |
| Packaging 1 - Qty | 500 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.003564m³ |
| Packaging 1 - Weight (kg) | 0.605362kg |
| Packaging 1 - Width (m) | 0.27m |
| Packaging 3 - Height (m) | 0.368m |
| Packaging 3 - Length (m) | 0.584m |
| Packaging 3 - Qty | 8000 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.083m³ |
| Packaging 3 - Weight (kg) | 10.641792kg |
| Packaging 3 - Width (m) | 0.386m |
| Packaging 4 - Height (m) | 1.249m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 96000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.199m³ |
| Packaging 4 - Weight (kg) | 148.728kg |
| Packaging 4 - Width (m) | 0.8m |
