21/10/2025

Cable clip with pipe/tube holder
Art.-No. 156-01240 | DTC14x18-S-PA66HIRHS-BK |

Copied
DTCs for easy assembly of rotatable routed tubes and harnesses.
DTC Tubeclip
DTC Tubeclip

    • Fixing clip offers full 360° rotation
    • For routing of two different bundles
    • Simply clip on a wire or hose
    • Suitable for post-installation of bundles
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application These pipe clips interconnect two different bundles of goods, of various size and type. The mobility of the fixing tie provides even in difficult conditions, such as vibrations, a secure grip and protects the cables or bundles.
    Colour Black (BK)
    Fixation Method Omega Clip
    Key product features rotatable, for multiple routing, removable
    Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    PART DESCRIPTION DTC14x18-S-PA66HIRHS-BK
    Pack Content 500pcs.
    Package Content packed in bag
    Product Family DTC - Double Tube Clip, rotatable 360°
    Product Group Fixing elements for tubes and harnesses
    Type DTC14x18-S
    Attach to ⌀ 14.0, 18.0
    Length (L) 47.2mm
    Width (W) 12.0mm
    GTIN-13 / EAN 4031026482767
    UNSPSC Key 39121705
