P-clamp closed, Dmax=31.5mm, ⌀5.2 mm, natural, 250pcs.
Art.-No. 211-60179
| H17P-PA66-NA
|
Copied
- Manufactured from Polyamide
- Good temperature resistance and high strength
- Wide range of sizes for every application
- Can be used without cable ties
Request quote
More products in this product group:
| Colour | Natural (NA) |
| Fixation Method | screw-hole |
| Material | Polyamide 6.6 (PA66) |
| PART DESCRIPTION | H17P-PA66-NA |
| Pack Content | 250pcs. |
| Package Content packed in | pcs. |
| Product Family | HP-Series |
| Product Group | Plastic P-Clamps |
| Type | H17P |
| Typical Application | For permanent or semi-permanent cable fixings this range of plastic P-Clamps can be used in many industries. Their light weight makes them particularly suitable for use in areas such as aircraft and aerospace where minimising weight, but retaining a strong fixing, is vitally important. |
| UV-Stabilised | No |
| Variant | Closed |
|
|
|
| GTIN-13 / EAN | 4031026129556 |
| Packaging 1 - Height (m) | 0.06m |
| Packaging 1 - Length (m) | 0.415m |
| Packaging 1 - Qty | 250 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.007221m³ |
| Packaging 1 - Weight (kg) | 0.65425kg |
| Packaging 1 - Width (m) | 0.29m |
| Packaging 3 - Height (m) | 0.204m |
| Packaging 3 - Length (m) | 0.591m |
| Packaging 3 - Qty | 1500 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.048m³ |
| Packaging 3 - Weight (kg) | 4.720868kg |
| Packaging 3 - Width (m) | 0.398m |
| Packaging 4 - Height (m) | 1.235m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 30000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.186m³ |
| Packaging 4 - Weight (kg) | 115.36kg |
| Packaging 4 - Width (m) | 0.8m |
