Solar I-Beam Clips
Art.-No. 151-04320
| IBBCLPSLR1-PA66HIRHSUV-BK
|
Copied
- Wide-body design prevents wobble caused by the lateral strain created during wire pull activities.
- Tool-free installation saves time and reduces installation costs.
- Clip-on styling for easy installation, even in constrained spaces.
- Cradle arms guide cabling and prevent bundles from escaping during pulling operations.
- Cable tie saddle for cinching down bundles when install is complete.
Show more
Show less
Request quote
More products in this product group:
| Application | The Solar I-Beam Clip is a cable routing device affixed to the top cross-section of an I-beam pile to reduce potential abrasion damage to PV cabling during cable pull operations. The oversized edge clip design can be top-loaded or rolled into position, making it easier to attach to the post even after panels have been installed and space is restricted. This top-of-beam clip accommodates a wide range of I-beam thicknesses, from 3.3mm to 12.7mm. The I-Beam Clip is easy to install, reduces wobble, holds more wires, and offers improved side-loading resistance. |
| Colour | Black (BK) |
| Compatible with | Nextpower |
| Description | The Solar I-Beam Clip is a cable routing device affixed to the top cross section of an I-beam pile to reduce potential abrasion damage to PV cabling during cable pull operations. The oversized edge clip design can be top loaded or rolled into position, making it easier to attach to the post even after panels have been installed and space is restricted. This top-of-beam clip accommodates a wide range of I-beam thicknesses from 0.125" to 0.50". The I-Beam Clip is easy to install, creates less wobble, holds more wires and has better side loading resistance. |
| Fixation Method | Edge Clip |
| For Ties | T18 - T50 |
| Material | Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV) |
| PART DESCRIPTION | IBBCLPSLR1-PA66HIRHSUV-BK |
| Pack Content | 250pcs. |
| Package Content packed in | pack |
| Product Family | Effectively routes PV cables |
| Product Group | Solar I-Beam Clips |
| Type | IBBCLPSLR1 |
| UV-Stabilised | Yes |
| Bundle ⌀ max. | 50.8mm |
| Bundle ⌀ min. | 48.76mm |
| Height (H) | 115.0mm |
| Height (H2) | 66.3mm |
| Hole Depth | 3.3mm |
| Hole Depth | 12.7mm |
| Length (L) | 21.0mm |
| Length (L2) | 12.2mm |
| Max. Tie Width (G) | 4.6mm |
| Panel Thickness | 0.125 - 0.5" |
| Panel Thickness | 3.3 - 12.7mm |
| Panel Thickness max. (imperial) | 0.5" |
| Panel Thickness min. (imperial) | 0.125" |
| Strap Width max. (G) | 0.18" |
| Width (W) | 119.8mm |
| Width (W2) | 2.95" |
| Width (W2) | 75.0mm |
| for Panel Thickness min - max | 3.3 - 12.7 mm |
| CE Certification | No |
| CSA Certified | No |
| Flammability | UL 94 HB |
| Halogen-free | No |
| Hazardous Goods | No |
| Operating Temperature | -40 °C to +110 °C |
| Operating Temperature, 1000h | +160 °C |
| Operating Temperature, 5000h | +125 °C |
| Operating Temperature, 500h | +165 °C |
| ROHS compliant | Yes |
| Reusable (Yes/No) | Yes |
| Specifications |
|
| UL Listed (US and Canada) | No |
| UL Listed (US) | No |
| UL Recognized (US and Canada) | No |
| UL Recognized (US) | No |
