Cable clip, T=0.6 - 9.0mm, Ø6.5 mm, Dmin=12.70mm, Dmax=19.56mm, black, 250pcs.
Art.-No. 156-02626 | IRCBFT6.5LG-PA66HIRHSUV-BK |  Details

High-performing round fir trees mean no additional fastener is needed for mounting.

    • One-piece ratchet closure allows for easy installation during pre- or final assembly
    • Easy release feature simplifies quick adjustments and maintenance
    • Impact modified, heat and UV stabilized PA66 provides long-term durability, indoors and out
    • High-performing round fir trees mean no additional fastener is needed for mounting
    Package size
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application The In-line Ratchet P-Clamp family offers versatility when managing wires, cables and hoses. The robust design and durable materials make it ideal for heavy duty applications, both indoors and out. The adjustable clamp can be closed by hand to the desired diameter. The release feature allows easy and nondestructive removal of cables simply by using a flat-head screwdriver. In this way, the clamp can be reused or serviced without removing it from the mounting surface.
    Colour Black (BK)
    Fixation Method Fir tree for round holes
    Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
    Pack Content 250pcs.
    Package Content packed in bag
    PART DESCRIPTION IRCBFT6.5LG-PA66HIRHSUV-BK
    Product Family In-Line Ratchet P-Clamp, B-Series
    Product Group Fixing elements with fir tree for round holes
    Bundle Diameter max (metric) 19.56mm
    Bundle ∅ min. 12.70mm
    for Hole ∅ (FH) 6.5 mm
    for Panel Thickness min - max 0.6 - 9 mm
    Length (L) 34.8mm
    Min.Tensile Strength 445N
    Panel Thickness 0.02 - 0.35"
    Panel Thickness max. 0.6 - 9.0mm
    Panel Thickness max. (imperial) 0.35"
    Panel Thickness min. (imperial) 0.02"
    Width (W) 34.9mm
    CE Certification No
    CSA Certified No
    Flammability UL 94 HB
    Operating Temperature -40 °C to +105 °C
    Specifications
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UV-Stabilised Yes
    GTIN-13 / EAN 4031026717456
    Packaging 3 - Height (m) 0.20954999999999998m
    Packaging 3 - Length (m) 0.517525m
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0344m³
    Packaging 3 - Width (m) 0.3175m
    UNSPSC Key 39121702
    Cable holder Cable holder

    Cable holder

    Looking for a secure way to fasten cables or wires? Our plastic cable holders are easy to install and suitable for almost any application. Learn more...

    Cable holder >
    Ratchet P Clamp Ratchet P Clamp

    Ratchet P-Clamp for mounting cables and hoses

    The Ratchet P Clamp family offers versatility when managing wires, cables and hoses, making it possible to fix wires, cables, hoses and pipes on a single mounting point in two separate work steps. The robust design and durable materials make it ideal for heavy duty applications, both indoors and out.
