Cable clip for hole (round), ⌀5.0 mm, Dmin=7.5mm, Dmax=8.5mm
Art.-No. 234-10400
| KK4-PA6HIR-BK
|
Copied
- Simple 1-screw fixing to guide and secure leads
- Two halves of the clip are linked to ensure no loss of parts during re-wiring
- Anti-rotation pin prevents leads from twisting
Request quote
More products in this product group:
| Application | Strain relief clips for gripping cables up to 8.5 mm bundle diameter. Strain relief clip is simply attached to mounting surface with an M4 fixing screw. |
| Colour | Black (BK) |
| Fixation Method | screw-hole |
| Material | Polyamide 6, high impact modified (PA6HIR) |
| PART DESCRIPTION | KK4-PA6HIR-BK |
| Pack Content | 500pcs. |
| Package Content packed in | pcs. |
| Product Family | Klam-Klip (KK) |
| Product Group | Strain relief clips |
| Type | KK4 |
| UV-Stabilised | No |
| Variant | Closed |
| ELV compliant (Article 4 - 2) | Yes |
| Flammability | UL 94 HB |
| Hazardous Goods | No |
| Operating Temperature | -40 °C to +80 °C |
| ROHS compliant | Yes |
| Specifications |
|
|
|
Source products are manufactured with plastics recovered from recycled waste or marine environments, derived from renewable plant-based sources, or use materials with lower equivalent emissions. HellermannTyton also offers product solutions that – by design – reduce waste or support reusability and recyclability. Sustainable design focuses on product solutions that reduce or avoid waste, i.e. products that can be completely or partially dismantled and repositioned, thus supporting reuse and recyclability. Longevity is not part of this. |
|
|
|
| GTIN-13 / EAN | 5022660308840 |
| Packaging 1 - Height (m) | 0.109m |
| Packaging 1 - Length (m) | 0.15m |
| Packaging 1 - Qty | 500 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.0053955m³ |
| Packaging 1 - Weight (kg) | 0.850001kg |
| Packaging 1 - Width (m) | 0.33m |
| Packaging 3 - Height (m) | 0.345m |
| Packaging 3 - Length (m) | 0.38m |
| Packaging 3 - Qty | 6000 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.0498m³ |
| Packaging 3 - Weight (kg) | 10.82kg |
| Packaging 3 - Width (m) | 0.38m |
| Packaging 4 - Height (m) | 1.258m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 108000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.208m³ |
| Packaging 4 - Weight (kg) | 215.76kg |
| Packaging 4 - Width (m) | 0.8m |
