Cable clip with pipe/tube holder, Dmin=10.5mm, Dmax=13.8mm, nomØ=12.0 mm, nomØ2=7.0 mm, black, 1000pcs.
Art.-No. 156-02081 | MOC12FMOC7M180-PA66HIRHSUV-BK |  Details

    Add to watchlist

    Request your individual offer now

     Request quote
    Colour Black (BK)
    Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
    Pack Content 1000pcs.
    Package Content packed in carton
    PART DESCRIPTION MOC12FMOC7M180-PA66HIRHSUV-BK
    Variant Clip to Clip Transverse
    Bundle Diameter max (metric) 13.8mm
    Bundle Diameter Nom. (ND) 12.0 mm
    Bundle Diameter Nom. 2 (ND2) 7.0 mm
    Bundle ∅ 2 max. 8.0mm
    Bundle ∅ 2 min. 6.0mm
    Bundle ∅ min. 10.5mm
    Depth (D) 10.0mm
    Height (H) 22.1mm
    Length (L) 36.09mm
    Length (L2) 19.7mm
    CE Certification No
    CSA Certified No
    Flammability UL 94 HB
    Halogen-free Yes
    Operating Temperature -40 °C to +110 °C
    Specifications
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UV-Stabilised Yes
    GTIN-13 / EAN 4031026716183
    Packaging 1 - Weight (kg) 201.98kg
    UNSPSC Key 39121702
