21/07/2026

Cable clip, Dmin=5.0mm, Dmax=5.0mm, nom⌀=3.95, nom⌀2=4.7


Art.-No. 151-02452

| PC4X2-5X2-PA66HIRHS-BK

 |

Copied
4x Pipe Clip secures four routings together while keeping them separated, to prevent chafing or heat transfer.

    Add to watchlist
    Request quote
    Downloads
    Colour Black (BK)
    Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    No. of bundles 2
    PART DESCRIPTION PC4X2-5X2-PA66HIRHS-BK
    Pack Content 10000pcs.
    Package Content packed in pack
    Type PC4X2-5X2
    UV-Stabilised No
    Bundle ⌀ max. 5.0mm
    Bundle ⌀ min. 5.0mm
    Bundle Diameter Nom. (ND) 3.95
    Bundle Diameter Nom. 2 (ND2) 4.7
    Height (H) 18.2mm
    Length (L) 16.7mm
    Width (W) 10.0mm
    CE Certification No
    CSA Certified No
    Flammability UL 94 HB
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US) No
    UL Recognized (US and Canada) No
    UL Recognized (US) No
    GTIN-13 / EAN 4031026715179
    Packaging 1 - Qty 10000
    Packaging 1 - Type pack
    Packaging 3 - Height (m) 0.1730375m
    Packaging 3 - Length (m) 0.57785m
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0349m³
    Packaging 3 - Width (m) 0.34925m
    UNSPSC Key 31162305
