Warning label, pre-printed, W=69.85mm, H=139.70mm, orange/white, pack=250pcs.
Art.-No. 596-00645
| WV55X275UV-336/926-OG
|
Copied
Request quote
| Colour | Orange (OG), White (WH) |
| Colour Marking Field | White (WH) |
| Colour of Print | Black (BK) |
| Key product features | pre-printed, chemical resistance |
| Marking Text | WARNING Header, Blank Yellow Triangle |
| Material | Type 336/926, Polyester, UV-stabilised, clear polyester laminate (336/926) |
| PART DESCRIPTION | WV55X275UV-336/926-OG/WH |
| Pack Content | 250pcs. |
| Package Content packed in | pack |
| Printable | Yes |
| Type | WV55X275UV |
| UV-Stabilised | Yes |
| Adhesive | Acrylic |
| Adhesive Operating Temperature | -40 °C to +150 °C |
| CE Certification | No |
| CSA Certified | Yes |
| Curing Temperature | +10 °C |
| Halogen-free | Yes |
| Operating Temperature | -40 °C to +150 °C |
| Pre-Printed | Yes |
| ROHS compliant | Yes |
| Recommended Ribbon Type | TT822OUT |
| Specifications |
|
| Specifications | ANSI Standard Z535.4, CSA 66956, IFC 2012, NEC2011, NEC2014, NEC2017, NEC2020, UL 969 |
| UL Listed (US and Canada) | No |
| UL Listed (US) | No |
| UL Recognized (US and Canada) | No |
| UL Recognized (US) | Yes |
| UL-File Number | MH14382, MH16736 |
