02/07/2026

Spiral reinforced conduit, nom⌀21mm, OD=21.2mm, ID=16.0mm, orange, 50.0m


Art.-No. 166-90961

| HG-SWSL0503F-PA6-OG

 |

Copied
PA6 material is easy to use and cut; reduces installation time and labor costs.

    Add to watchlist
    Request quote
    Downloads
    Colour Orange (OG)
    Material Polyamide 6 (PA6)
    PART DESCRIPTION HG-SWSL0503F-PA6-OG
    Pack Content 50.0m
    Package Content packed in reel
    Pitch Type fine
    Type HG-SWSL0503F
    Inner Diameter D (Imperial) 0.63"
    Inside ⌀ (ID) 16.0mm
    Length (L) 50.0m
    Nominal ⌀ 1/2"
    Nominal ⌀ 21mm
    Outside ⌀ (OD) 21.2mm
    Outside ⌀ (OD) 0.84"
    CE Certification No
    CSA Certified No
    Flammability UL 94 V2
    Halogen-free Yes
    Operating Temperature -40 °C to +120 °C
    ROHS compliant Yes
    Specifications
    UL Recognized (US) No
    GTIN-13 / EAN 4031026646107
    Reel Length 164ft
    Reel Length 50.0m
    UNSPSC Key 39131601
