Fitting, nom⌀16mm, black, 10pcs.


Art.-No. 166-90230

| HG038-HG038-PA66-BK

 |

Copied

Colour Black (BK)
Material Polyamide 6.6 (PA66)
Material Fitting Polyamide (PA)
PART DESCRIPTION HG038-HG038-PA66-BK
Pack Content 10pcs.
Package Content packed in bag
Strain Relief Function (Y/N) No
Swivel Thread (Y/N) No
Type HG038-HG038
Type of connection Snap-connection
UV-Stabilised No
Variant Coupler
Bore Diameter (Imperial) 0.43"
Bore Diameter (metric) 11.0
From Nominal Diameter (Imperial) 3/8
From nominal diameter 16.0mm
Length (L) 59mm
Nominal ⌀ 0.38"
Nominal ⌀ 16mm
Outside ⌀ (OD) 29mm
Outside ⌀ (OD) 1.14"
To Nominal Diameter (Imperial) 3/8
To nominal diameter 16mm
Flammability UL 94 V2
Halogen-free Yes
IP-Rating IP66
Operating Temperature -50 °C to +135 °C
ROHS compliant Yes
Specifications
UL Listed (US and Canada) No
UL Listed (US) No
UL Recognized (US and Canada) Yes
UL Recognized (US) Yes
UL-File Number E229161
GTIN-13 / EAN 4031026466705
UNSPSC Key 39131708
