Accessories for Helawrap Cable Cover : HWCLIP08

Fixing clip PA66HIRHS nominal ∅ 8mm black, Article number: 161-64002

Features

  • Mounts and routes Helawrap cable cover flexibly and efficiently
  • Fit snugly around the cable cover and holds it tight
  • Each clip can be joined to mounting plate or other clips of any size
  • Each clip rotates freely
  • Easily released and re-used

Certifications & Approvals

Application

To complete the Helawrap cable management system various Helawrap Clips in compatible sizes are available.
The mounting clips can be combined and adjusted individually. Attached to a mounting base the assembly can be screw mounted or directly sticked to the surface.

HWClips is suitable for following markets and industries

Colour Black (BK)
Fixation Method Plug-in mounting
Pack Content 50pcs.
Package Quantity per bag
PART DESCRIPTION HWCLIP08-PA66HIRHS-BK
Product Family HWClips
Product Group Accessories for Helawrap Cable Cover
Diameter (D) 9mm
Nominal ∅ 8.0mm
Nominal ∅ 5/16"
∅ D 0.375"
CSA Certified No
ELV compliant (Article 4 - 2) YES
Flammability UL 94 HB
Halogenfree Yes
Hazardous good No
Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
Material PA66HIRHS
Melting Point +284 °F (+140 °C)
Operating Temperature - °C -40 °C to +105 °C
Specifications
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
EAN / GTIN 4031026268552
Packaging 1 - Height (m) 0.025m
Packaging 1 - Length (m) 0.125m
Packaging 1 - Qty 50
Packaging 1 - Type bag
Packaging 1 - Volume (m³) 0.00059
Packaging 1 - Weight (kg) 0.091137kg
Packaging 1 - Width (m) 0.19m
Packaging 3 - Height (m) 0.184m
Packaging 3 - Length (m) 0.58m
Packaging 3 - Qty 2000
Packaging 3 - Type carton
Packaging 3 - Volume (m³) 0.0406
Packaging 3 - Weight (kg) 4.24548kg
Packaging 3 - Width (m) 0.38m
Packaging 4 - Height (m) 1.249m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 48000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.199
Packaging 4 - Weight (kg) 122.76kg
Packaging 4 - Width (m) 0.8m
Weight 0.19lbs
Weight 0.066kg
UNSPSC Key 39131604

Stay in touch with us!


Update: 18/08/2019 © HellermannTyton 2019
