Cable tie mount, T=1.0 - 3.0mm, black, 5000pcs.
Art.-Nr. 102-68310 | ATS-EC9-PA66HIRHS-BK |

Copied

    • Optimized for use automatic cable tying systems
    • Easy to apply
    • The fixing elements can be tied automatically with Autotool System ATS
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application Clips to fix cables and harnesses in the automotive and white goods industry.
    Colour Black (BK)
    Fixation Method Edge Clip
    Key product features products for automatic tools
    Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    PART DESCRIPTION ATS-EC9-PA66HIRHS-BK
    Pack Cont. 5000pcs.
    Package Content packed in bag
    Product Family EdgeClip-Series for automatic cable tying systems
    Product Group Automatic bundling
    Short Description Footparts for Autotool System
    Type ATS-EC9
    Height (H) 17.5mm
    Length (L) 15mm
    Panel Thickness max. 1.0 - 3.0mm
    Width (W) 9.1mm
    for Panel Thickness min - max 1 - 3 mm
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Specifications
    Country of Origin CN
    GTIN-13 / EAN 4031026624099
    ETIM 7.0 Key EC000449
    ETIM 8.0 Key EC000449
    ETIM 9.0 Key EC000449
    UNSPSC Key 39121717
