Cable tie mount for screw fixation, Wmax=5.0mm, ⌀5.0 x 19.0 mm, #10 (M5) Screw, white, 1000pcs.
Art.-Nr. 151-00288 | CTAP1-PA66-WH |

Copied
Cable tie anchor mounts are installed quick and easy by securing a single screw.
Cable tie anchor mounts are installed quick and easy by securing a single screw.
Detectable fixing solution containing of MCCTAM1 mount and MCTS cable tie.
Cable tie anchor mounts are installed quick and easy by securing a single screw.
Cable tie anchor mounts are installed quick and easy by securing a single screw.
CTAM-Series (side view)

    • Suitable for applications with minimal space
    • Mounted before cable installation and in line with cable
    • CTAP mounts offer adjustable stand off feature for precision placement
    Package size
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application Each of these products offers particular benefits, but all are designed for simple, yet robust, installation in a wide variety of applications - particularly used in telecoms equipment, switchgear and control cabinets.
    Colour White (WH)
    Fixation Method Screw Mount
    For Ties T18 - T50
    Material Polyamide 6.6 (PA66)
    Mounting Screw Type #10 (M5) Screw
    PART DESCRIPTION CTAP1-PA66-WH
    Package Content 1000pcs.
    Package Content packed in pack
    Product Family CTAM-Series for applications where space is limited
    Product Group Screw fixing mounts
    Type CTAP1
    UV-Stabilised No
    Weight/Unit 0.001994kg
    Height (H) 3.80mm
    Length (L) 34.0mm
    Strap Width max. (G) 0.2"
    Strap Width max. (G) 5.0mm
    Width (W) 12.7mm
    for Hole ⌀ (FH) 5.0 x 19.0 mm
    CE Certification Yes
    CSA Certified No
    ELV compliant (Article 4 - 2) YES
    Flammability UL 94 V2
    Hazardous Goods No
    Operating Temperature -40 °C to +85 °C
    ROHS compliant Yes
    Specifications
    Specifications UL
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) Yes
    UL Recognized (US) Yes
    UL-File Number E64139
    Country of Origin US
    Customs Number 39269097
    GTIN-13 / EAN 4031026430287
    Packaging 1 - Qty 1000
    Packaging 1 - Type pack
    Packaging 1 - Weight (kg) 1.994001kg
    Packaging 3 - Height (m) 0.20955m
    Packaging 3 - Length (m) 0.5175m
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0344m³
    Packaging 3 - Width (m) 0.3175m
    ETIM 7.0 Key EC000449
    ETIM 8.0 Key EC000449
    ETIM 9.0 Key EC000449
    UNSPSC Key 39121717
