Cable tie mount with pipe/tube holder, Ø8.2 mm, black, 500pcs.
Art.-Nr. 151-03253 | HDCM2A-PA66GF15-BK |  Details

Separates and secures bundles or convoluted tubing to prevent abrasion.

    Add to watchlist

    Request your individual offer now

     Request quote
    Colour Black (BK)
    Key product features for multiple routing, releasable
    Material Polyamide 6.6, glass-fibre reinforced (PA66GF15)
    Pack Cont. 500pcs.
    Package Content packed in bag
    PART DESCRIPTION HDCM2A-PA66GF15-BK
    Variant Separators
    Bundle Diameter max (metric) 23.7mm
    Bundle ∅ 23.7-23.7mm
    Bundle ∅ min. 23.7mm
    for Hole ∅ (FH) 8.2 mm
    Height (H) 34mm
    Length (L) 69.1mm
    Width (W) 28.48mm
    ∅ max. 1. loop 23.7mm
    ∅ max. 2. loops 23.7mm
    CE Certification No
    CSA Certified No
    Operating Temperature -40 °C to +125 °C
    Specifications
    UV-Stabilised No
    Country of Origin MX
    GTIN-13 / EAN 4031026646558
    ETIM 7.0 Key EC000449
    ETIM 8.0 Key EC000449
    ETIM 9.0 Key EC000449
    UNSPSC Key 39121717
    Self-Adhesive cable tie mounts Self-Adhesive cable tie mounts

    Self-Adhesive cable tie mounts

    HellermannTyton self-adhesive cable tie mounts are perfectly suited for cable fastening on round and angled surfaces. To save time, reduce part diversity and weight.
