Fixing tie for hole (round), outside serrated, ⌀4.0-45.0mm, black, 500pcs.
Art.-Nr. 156-03581
| S50ROSFT8-PP/PA66HS-BK
|
Copied
- Pre-assembled 2-piece fixing tie with fir tree foot part
- Cable tie head can be moved after bundling
- The S50ROS features a significantly lower CO₂ footprint compared to cable ties made of standard material, in line with sustainability goals in various industries
- The outside serration design ensures gentle handling of sensitive cables and bundles, reducing the risk of damage during installation and maintenance
- With an anti-slip feature on the inside, the S50ROS prevents undesired lateral movement of cables and bundles, maintaining tidy and organized cable management within vehicles
- Disc adjusts tie for pressure from various directions and minimises access of dust and dirt
- Fir tree foot part can be used for a variety of panel thicknesses
- Suitable for use within threaded holes
Show more
Show less
Request quote
More products in this product group:
2-piece fixing ties with fir tree, with disc, for round holes
| Application | S-Series cable ties made from Polypropylene (PP) are non hydroscopic, offer a higher chemical resistance and reduced CO2 footprint compared to a standard cable tie material. These cable ties are used to bundle and secure cables, pipes and/or hoses. |
| Cable Tie | Polypropylene (PP) |
| Colour | Black (BK) |
| Fixation Method | Fir Tree |
| Foot Part | Polyamide 6.6, heat stabilised (PA66HS) |
| Identification Plate Position | none |
| Material | Polypropylene (PP), Polyamide 6.6, heat stabilised (PA66HS) |
| Min.Tensile Strength | 185N |
| Mounting Screw Type | Plated through hole |
| PART DESCRIPTION | S50ROSFT8-PP/PA66HS-BK |
| Package Content | 500pcs. |
| Package Content packed in | bag |
| Product Family | Fir tree parts FT8 |
| Product Group | 2-piece fixing ties with fir tree, with disc, for round holes |
| Releasable Closure (Yes/No) | No |
| Short Description | 2-Piece Fixing tie with fir tree, 200.0x4.9mm, for round holes 7,7-8.0mm, black |
| Tie Closure | plastic pawl |
| Type | S50ROSFT8 |
| Variant | Outside Serrated with AntiSlip Engraving |
| Weight/Unit | 0.0025kg |
|
|
|
| Bundle ⌀ | 4.0-45.0mm |
| Bundle ⌀ max. | 45.0mm |
| Bundle ⌀ min. | 4.0mm |
| Cable Tie Head Height (metric) | 7.5mm |
| Cable Tie Head Length (metric) | 8.3mm |
| Cable Tie Head Width (metric) | 8.95mm |
| Disc ⌀ | 16.0mm |
| Height (H) | 1.45mm |
| Height (H2) | 17.8mm |
| Hole Depth | 11.5mm |
| Length (L) | 200.00mm |
| Panel Thickness | 0.8 - 6.0mm |
| Thickness (T) | 1.45mm |
| Width (W) | 4.90mm |
| for Hole ⌀ (FH) | 7.7 - 8.0 mm |
| for Panel Thickness min - max | 0.8 - 6 mm |
| ELV compliant (Article 4 - 2) | Yes |
| Hazardous Goods | No |
| Operating Temperature | -40 °C to +110 °C, (3000 h) |
| ROHS compliant | Yes |
| Specifications |
|
|
|
Source products are manufactured with plastics recovered from recycled waste or marine environments, derived from renewable plant-based sources, or use materials with lower equivalent emissions. HellermannTyton also offers product solutions that – by design – reduce waste or support reusability and recyclability. ReSource highlights HellermannTyton products that are made from recycled waste or from virgin materials with relatively lower carbon emissions. |
|
|
|
| Country of Origin | PL |
| Customs Number | 39269097 |
| GTIN-13 / EAN | 4031026752426 |
| Packaging 1 - Height (m) | 0.1m |
| Packaging 1 - Length (m) | 0.45m |
| Packaging 1 - Qty | 500 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.017775m³ |
| Packaging 1 - Weight (kg) | 1.279135kg |
| Packaging 1 - Width (m) | 0.395m |
| Packaging 3 - Height (m) | 0.538m |
| Packaging 3 - Length (m) | 0.584m |
| Packaging 3 - Qty | 5000 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.1213m³ |
| Packaging 3 - Weight (kg) | 13.79905kg |
| Packaging 3 - Width (m) | 0.386m |
| Packaging 4 - Height (m) | 1.22m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 40000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.171m³ |
| Packaging 4 - Weight (kg) | 132.384kg |
| Packaging 4 - Width (m) | 0.8m |
