BPINSERT
Art.-Nr. 854-44225 | BPINSERT |

Standard keystone style interface
RJ45 terminated to a 110 IDC PCB connector
Jack life a maximum of 1,000 insertions
Contact set constructed of phosphor bronze material with 50 micro-inch gold plating
Components manufactured from UL94V-0 thermoplastic material
Unique strain relief design secures cable terminations
Innovative crosstalk cancellation technology – 10 internal contacts (two extra to cancel out crosstalk) and 8 external contacts in standard configuration to accept industry standard patch cords
Staggered contacts provide superior performance
Configured with both 568A and 568B wiring schemes
IDC accepts 22-26 AWG solid twisted-pair cable
Available in 12 colors to match any faceplate or color coding identification
Palm tool available for easy on-site installation
RJ45 jacks are factory tested 200 times with an RJ11 plug (4P or 6P) to ensure there is no damage to the contacts.
Each jack is individually tested three times to ensure quality performance
IDC is factory tested to 50 terminations
