TT230SM-PL-BK : TT230SM
Art.-Nr. 556-00230 | TT230SM-PL-BK |  Details

    • Premium TT4000+ printer series - intended for heavy-duty industrial applications
    • High quality 300dpi print head is available and is ideally suited for high definition graphic
    • Highly effective and reliable printer able to produce medium and high volume labels, heatshrink, and Tiptags
    • Print speeds up to 125mm per second (5" per second) are possible dependant on the material you wish to print
    • Standard TT430 printer - entry-level 300dpi printer that is specifically designed to run HellermannTyton’s standard range of adhesive labels and ShrinkTrak
    • Best suited for those with small to medium volume print runs
    • Standard range of HellermannTyton ribbons can also be used
    Show more
    Add to watchlist

    Request your individual offer now

     Request quote
    Colour Black (BK)
    Material Plastic (PL)
    Pack Cont. 1pc.
    Package Content packed in EA
    PART DESCRIPTION TT230SM-PL-BK
    Print resolution DPI 300dpi
    Depth (D) 279.4mm
    Height (H) 172.0mm
    Label Width Max (imperial) 4.40"
    Label Width Min (imperial) 1.0"
    Label Width min - max 25.4 - 111.8 mm
    Length (L) 279.4mm
    Print Material Height Max (metric) 990.6mm
    Print Material Width Max (metric) 111.76mm
    Print Material Width Min (metric) 25.4mm
    Print Method thermal transfer print
    Width (W) 201mm
    CE Certification Yes
    CSA Certified No
    Max. Print Width 101.6mm
    Max. Print Width 4"
    Operating Temperature +4 °C to +40 °C
    Printer Memory 8MB RAM
    Specifications
    UL Listed (US and Canada) Yes
    UL Recognized (US and Canada) No
    UL-File Number E178707
    UV-Stabilised No
    Country of Origin CN
    Dimensions W x H x D 201 mm x 172.0 mm x 279.4 mm
    GTIN-13 / EAN 4031026408118
    Packaging 1 - Weight (kg) 6.8kg
    Storage Temperature -34 °C to +71 °C
    ETIM 7.0 Key EC001672
    ETIM 8.0 Key EC001672
    ETIM 9.0 Key EC001684
    UNSPSC Key 39131505
    Variant desktop
    Thermal transfer printer TT431 Thermal transfer printer TT431

    Thermal transfer printer for industrial-grade printing

    Thermal Transfer Printer >
