Cable tie inside serrated, 300.0x7.7mm, ⌀6.0-70.0mm, natural, 100pcs.

???product.artNr??? 109-00024

| Q120I-PA66-NA

|

2. Pull the tie through the head until the bundle is fixed. 3. Cut off the remaining part of the tie with an application tool.

1. Insert tail into lock head and push tail partly in the head

Q-ties can be used for both temporary and final cable installation.

5. The thin part of the cable tie can be simply placed into the open lock head. 6. The large ribbed tail allows a safe and ergonomic installation. 7. Integrated pre locking feature (starts with type Q30).

1. Open lock head for quick and easy insertion 2. Two rails on the strap ensure a perfect guidance for the tracks in the head 3. The locking device interacts safely with the serration of the cable tie 4. The tracks prevent a deformation of the head under load.

Q-tie cable ties: choose from a wide product range in different materials.

3. When installation is finished, Q-tie can be tightened and cut off - either manually or with an application tool.

2. To release the tie push tail end slightly out of head.

Even under difficult circumstances the Q-tie cable tie is very fast and easy to apply.

The Q-mount base locks the Q-tie in vertical position, your hands are free to apply the cables.

1. Insert the thin part of the cable tie into the open lock head.

???product.discontinued???

???product.discontinued.replaced???

???product.discontinued.compare???

Open lock head for quick and easy insertion
Integrated pre-locking function
More than 25 % faster in application
Inside serration for a strong hold around bundles
Easy application either manually or with a processing tool

???product.details.showmore???

???downloads??? ???contentsearch.documenttype.HubELearning???

???product.productgroup.title???:

Cable Ties with open head

Base Data

???product.application???	Q-Series cable ties for bundling and securing cables, pipes and hoses. The innovative and effective cable ties enable a simple and quick installation.
Colour	Natural (NA)
Identification Plate Position	none
Material	Polyamide 6.6 (PA66)
Min.Tensile Strength	530N
PART DESCRIPTION	Q120I-PA66-NA
Pack Content	100pcs.
Package Content packed in	bag
Product Family	Q-ties, Polyamide 6.6 (PA66), natural and black
Product Group	Cable Ties with open head
Releasable Closure (Yes/No)	No
Tie Closure	plastic pawl
Type	Q120I
Variant	Inside Serrated

Product Dimensions


Bundle ⌀ max.	70.0mm
Bundle ⌀ min.	6.0mm
Length (L)	300.0mm
Max. Tie Width (G)	7.7mm
Strap Width max. (G)	0.303"
Strap Width max. (G)	0.52"
Thickness (T)	1.8mm
Width (W)	7.7mm

???downloads???

Technical drawing

???download???

Specifications

ELV compliant (Article 4 - 2)	Yes
Flammability	UL 94 V2
Halogen-free	Yes
Hazardous Goods	No
Operating Temperature	-40 °C to +85 °C
ROHS compliant	Yes
Specifications
Specifications	ANSI/UL 1565, ANSI/UL 62275, ANSI/UL 746B
UL File link	???product.externalLink???
UL Listed (US and Canada)	Yes
UL Listed (US)	Yes
UL Recognized (US and Canada)	No
UL Recognized (US)	No
UL-File Number	E65344

Logistics and Packaging


GTIN-13 / EAN	4031026410142
Packaging 1 - Height (m)	0.045m
Packaging 1 - Length (m)	0.46m
Packaging 1 - Qty	100
Packaging 1 - Type	bag
Packaging 1 - Volume (m³)	0.00414m³
Packaging 1 - Weight (kg)	0.490001kg
Packaging 1 - Width (m)	0.2m
Packaging 3 - Height (m)	0.27m
Packaging 3 - Length (m)	0.59m
Packaging 3 - Qty	2000
Packaging 3 - Type	carton
Packaging 3 - Volume (m³)	0.0621m³
Packaging 3 - Weight (kg)	10.63002kg
Packaging 3 - Width (m)	0.39m
Packaging 4 - Height (m)	1.224m
Packaging 4 - Length (m)	1.2m
Packaging 4 - Qty	32000
Packaging 4 - Type	pallet
Packaging 4 - Volume (m³)	1.175m³
Packaging 4 - Weight (kg)	191.08kg
Packaging 4 - Width (m)	0.8m

More Information

UNSPSC Key

39121703
