07/07/2026

Releasable cable tie, 370.0x12.6mm, ⌀13.0-100.0mm, 1115N, black, 100pcs.


Art.-No. 115-00157

| SR255X-PA66HIRHSUV-BK

 |

Copied
  • Releasable and reusable cable tie
  • Suitable for lager and heavier bundles
  • Extended trigger for simple and quick release of ties
  • Protected trigger to avoid accidental release
Application SR255 Series heavy-duty cable ties offer a release feature in the head allowing for easy installation with the use of a cable tie tool. The head design guarantees high tensile strength even after repeated use, as well as a low insertion force.
Colour Black (BK)
Fixation Method Releasable Cable Tie
Identification Plate Position none
Key product features releasable
Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
Min.Tensile Strength 1115N
PART DESCRIPTION SR255X-PA66HIRHSUV-BK
Pack Content 100pcs.
Package Content packed in pack
Product Family SR255-Series
Product Group Cable ties releasable for heavier bundles
Releasable Closure (Yes/No) Yes
Type SR255X
UV-Stabilised Yes
Bundle ⌀ max. 100.0mm
Bundle ⌀ min. 13.0mm
Length (L) 370.0mm
Strap Width max. (G) 0.49"
Width (W) 12.6mm
CE Certification No
CSA Certified No
Flammability UL 94 HB
Operating Temperature -40 °C to +105 °C
ROHS compliant Yes
Reusable (Yes/No) Yes
Specifications
UL Listed (US and Canada) No
UL Listed (US) No
UL Recognized (US and Canada) No
UL Recognized (US) No
GTIN-13 / EAN 4031026687391
Packaging 1 - Qty 100
Packaging 1 - Type bag
Packaging 3 - Height (m) 0.20955m
Packaging 3 - Length (m) 0.5175m
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.0344
Packaging 3 - Weight (kg) 10.71kg
Packaging 3 - Width (m) 0.3175m
UNSPSC Key 39121703
