Fixing tie for hole (oval), ⌀7-34mm, black, 50pcs.


Art.-No. 126-00365

| OF160DB-WPM712-PA66HSW-BK

 |

Copied
  • Bundling and fixing solution
  • Ideal combination of materials and design
  • Different positions of the fixing anchor are available to fit installation space
Colour Black (BK)
Identification Plate Position none
Material Polyamide 6.6, heat and UV-resistant (PA66HSW)
Min.Tensile Strength 150N
PART DESCRIPTION OF160DB-WPM712-PA66HSW-BK
Pack Content 50pcs.
Package Content packed in bag
Product Family OF160DB-WPM712
Product Group 1-Piece Fixing Ties with Arrowhead, with Wings
Releasable Closure (Yes/No) No
Type OF160DB-WPM712
Typical Application For bundling and fixing of cable harnesses, pipes and hoses in many different industries, including automotive, aerospace, white goods manufacturing and panel building.
Bundle ⌀ max. 34mm
Bundle ⌀ min. 7mm
Height (H) 13.5mm
Length (L) 160mm
Thickness (T) 1.3mm
Width (W) 60mm
for Hole ⌀ (FH) 7.0 x 12.0 mm
for Panel Thickness min - max 0.5 - 2.6 mm
Flammability UL 94 V2
Halogen-free Yes
Operating Temperature -40 °C to +110 °C
ROHS compliant Yes
Specifications
GTIN-13 / EAN 4944387120080
UNSPSC Key 39121703
