Fixing tie with pipe/tube holder, ⌀14.0-18.3mm, black, 1000
Art.-No. 156-01751
| T50SMVCMOC16M180-PA66HIRHSUV-BK
|
Copied
| Cable ⌀ max | 50.0mm |
| Cable ⌀ min | 2.0mm |
| Colour | Black (BK) |
| Fixation Method | Omega Clip |
| Identification Plate Position | none |
| Key product features | lockable, rotatable |
| Material | Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV) |
| Min.Tensile Strength | 225N |
| PART DESCRIPTION | T50SMVCMOC16M180-PA66HIRHSUV-BK |
| Pack Content | 1000 |
| Package Content packed in | pack |
| Product Group | 2-piece fixing ties with pipe clip |
| Type | T50SMVCMOC16M180 |
| UV-Stabilised | Yes |
| CE Certification | No |
| CSA Certified | No |
| ELV compliant (Article 4 - 2) | Yes |
| Flammability | UL 94 HB |
| Halogen-free | Yes |
| Hazardous Goods | No |
| Operating Temperature | -40 °C to +105 °C |
| ROHS compliant | Yes |
| Specifications |
|
| UL Listed (US and Canada) | No |
| UL Listed (US) | No |
| UL Recognized (US and Canada) | No |
| UL Recognized (US) | No |
|
|
|
| GTIN-13 / EAN | 4031026586403 |
| Packaging 1 - Qty | 1000 |
| Packaging 1 - Type | pcs. |
| Packaging 1 - Weight (kg) | 2.9kg |
| Packaging 3 - Height (m) | 0.216m |
| Packaging 3 - Length (m) | 0.60801m |
| Packaging 3 - Qty | 3000 |
| Packaging 3 - Type | carton |
| Packaging 3 - Volume (m³) | 0.0521m³ |
| Packaging 3 - Weight (kg) | 9.25kg |
| Packaging 3 - Width (m) | 0.396875m |
| Packaging 4 - Height (m) | 1.22m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 60000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.171m³ |
| Packaging 4 - Weight (kg) | 206.0kg |
| Packaging 4 - Width (m) | 0.8m |
