Fixing tie with pipe/tube holder, ⌀17.0-21.8mm, black, 1000pcs.
Art.-No. 156-01790 | T50SMVCMOC19M180-PA66HIRHSUV-BK

Copied
Cable ⌀ max 50.0mm
Cable ⌀ min 2.0mm
Colour Black (BK)
Fixation Method Omega Clip
Identification Plate Position none
Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
PART DESCRIPTION T50SMVCMOC19M180-PA66HIRHSUV-BK
Pack Content 1000pcs.
Package Content packed in pack
Product Group 2-piece fixing ties with pipe clip
Type T50SMVCMOC19M180
UV-Stabilised Yes
Bundle ⌀ max. 21.8mm
Bundle ⌀ min. 17.0mm
Bundle Diameter Nom. (ND) 19.0 mm
Depth (D) 12.0mm
Height (H) 44.6mm
Length (L) 27.3mm
Length (L2) 21.4mm
Min.Tensile Strength 225N
CE Certification No
CSA Certified No
Flammability UL 94 HB
Halogen-free Yes
Operating Temperature -40 °C to +105 °C
ROHS compliant Yes
Specifications
UL Listed (US and Canada) No
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
UL Recognized (US) No
GTIN-13 / EAN 4031026587455
Packaging 1 - Type carton
Packaging 1 - Weight (kg) 203.43kg
Packaging 3 - Height (m) 0.216m
Packaging 3 - Length (m) 0.60801m
Packaging 3 - Type carton
Packaging 3 - Volume (m³) 0.0521
Packaging 3 - Width (m) 0.396875m
UNSPSC Key 39121702
