Fixing tie with pipe/tube holder, ⌀20.0-25.0mm, black, 1000pcs.
Art.-No. 156-02259 | T50SVCMOC22M180-PA66HIRHSUV-BK

Copied
Cable ⌀ max 35.0mm
Cable ⌀ min 2.0mm
Colour Black (BK)
Fixation Method Omega Clip
Identification Plate Position none
Key product features lockable, rotatable
Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
Min.Tensile Strength 225N
PART DESCRIPTION T50SVCMOC22M180-PA66HIRHSUV-BK
Pack Content 1000pcs.
Package Content packed in pack
Product Group 2-piece fixing ties with pipe clip
Type T50SVCMOC22M180
UV-Stabilised Yes
Bundle ⌀ max. 25.0mm
Bundle ⌀ min. 20.0mm
Bundle Diameter Nom. (ND) 22.0 mm
Depth (D) 12.0mm
Height (H) 47.8mm
Length (L) 30.5mm
Length (L2) 22.9mm
CE Certification No
CSA Certified No
Flammability UL 94 HB
Halogen-free Yes
Operating Temperature -40 °C to +105 °C
ROHS compliant Yes
Specifications
UL Listed (US and Canada) No
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
UL Recognized (US) No
GTIN-13 / EAN 4031026717883
Packaging 1 - Type bag
Packaging 1 - Weight (kg) 203.76kg
Packaging 3 - Height (m) 0.216m
Packaging 3 - Length (m) 0.60801m
Packaging 3 - Qty 1000
Packaging 3 - Type carton
Packaging 3 - Volume (m³) 0.0521
Packaging 3 - Weight (kg) 4.47kg
Packaging 3 - Width (m) 0.396875m
Packaging 4 - Qty 30000
UNSPSC Key 39121702
